Raw worklog

2015-11-24

TLDR
- CapTech Workshop. Was great!
- Acted upon a split between a FPGA long-term approach, and a non-FPGA one. I remembered those good old times when this was a possibility.
- Damn it. What if I could dig into this? Not µC, rather an extension for an existing computer.. or mini computer.
- Saw some ideas on the Arduino's side. Separate ADC.
Resources
- Is Pi powerful enough for an oscilloscope project?
- Raspberry Pi as an Oscilloscope @ 10 MSPS

2015-11-27

http://paul.sullivan.za.org/raspberry-pi-oscilloscope/EE-October-1991/ (pics below)
MagPi : ISSUE 24 - JUN 2014 (to print !!)
Follow up
- Discussion with 4365D2F5E4EB59B6BAD0FC746506A6EADEC28BC264BDD78BC041D3417B0766F4
- Discussion with 8620B4ADDED83F8C1E5EBC0F401D12BC327735D7A314336D24C3F3D88A16E3ED

2015-11-28

Tamagotchi hive in a probe?
Thinking about the smile on the silkscreen. EO+OH+PI+Pirate?

2015-12-01

Thinking of deadlines
PHH/BM discussions
- Rather be going onto SPI : QuadSPI ?
- LTC5507ES6 to filter ? A rajouter!
- Better ADC at LTC2315-12
- DAC: a simple DAC i2c
Pro/Cons of a shield compared to FPGA/microcontrolleur

2015-12-02

Rasberry Pirn
- Raspberry Pi Zero Headless Setup : http://davidmaitland.me/2015/12/raspberry-pi-zero-headless-setup/
- Installing Operating System Images on Linux https://www.raspberrypi.org/documentation/installation/installing-images/linux.md
BBB
- How to use it?
  - http://www.element14.com/community/community/designcenter/single-board-computers/next-gen_beaglebone//blog/2013/05/22/bbb--working-with-the-pru-icssprussv2
  - For low-speed comms, conventional I2C or similar protocols can be used, and there is no need to use a PRU. For high-speed comms the PRU may be extremely useful because it can service the hardware with no interruptions due to Linux context switching, and no overhead is experienced by the main ARM processor. Here are some examples that should be feasible; basically quite a few possibilities, such as
  - - interfacing to a fast ADC (e.g. analog capture) ,
- https://theembeddedkitchen.net/beaglelogic-building-a-logic-analyzer-with-the-prus-part-1/449 BBB is a 100MHz logic analyzer on a BeagleBoneBlack
- Demo over the http://beaglelogic.github.io/webapp/
- http://r.git.net/beagleboard/2013-10/msg00204.html
  - Can the PRU be used to interface the Beaglebone to external ADC? I need to capture 500 micro-seconds of data at a 5 MHz rate.
  - -> It depends on the interface to the ADC. There is a parallel capture interface that will easily run that fast, and you may be able to use the bit-shift interface to do serial or something like SPI if the PRU's capability lines up with what your ADC wants to see.
- http://www.element14.com/community/community/designcenter/single-board-computers/next-gen_beaglebone//blog/2013/08/04/bbb--high-speed-data-acquisition-and-web-based-ui
  - In its current state, it grabs analog data from an ADC, and dumps it into memory on the BBB, ready to be displayed or further processed. It could be used for gathering analog information from sensors, CCDs or other data acquisition use-cases. To be reasonably useful, the desire was for it to support 20Mbytes/sec of data or more. It does achieve this, but it is for further study to find higher speed methods.*
  - This is not such a bad idea, because in future the ADC could be swapped out to a (say) 10-bit ADC with no code change on the PRU.*
  - Once the data has been captured (2000 samples in this example), the command byte is acknowledged, so that the Linux hosted application can know that the PRU has completed. The PRU now sits and waits for a new instruction from the Linux hosted application. -> works for us - fixed depth = fixed # of samples
- Buffer to be used : detailed at http://www.element14.com/community/community/designcenter/single-board-computers/next-gen_beaglebone//blog/2013/08/04/bbb--high-speed-data-acquisition-and-web-based-ui
  - ''These were extremely important for two reasons. One reason is that the pins to the BBB that I wished to use need to be isolated during power-up, because they are used for selecting the boot method. If there was any unusual level on the pins upon power-up then the BBB will not boot from the eMMC. So, a tri-state buffer is needed. The other reason is that there is a fair bit of capacitance and it is highly likely that the ADC may not be able to directly drive the pins at high speed. I actually came across this problem while trying to connect a camera to the BBB. I struggled for days without realising that the camera could not support the load. So, the buffers are likely to be essential for most designs using the pins that were selected. I used a 74LVC244A device as a buffer. Note that the clock also needs a buffer, unless significant jitter is acceptable. No tri-state is required here, so I used a MC74VHC1GT50.

2015-12-03

New ADCs in mind ADS803E LTC2315-12
Orange Pi Plus 2 : A nasty little thing
BBB as always coming mostly from element14 Some limits - not exploiting all ? http://exploringbeaglebone.com/chapter13/#The_ADS7883_Single-Channel_12-bit_ADC_1MSps_max SPI speed with BBB : http://fr.mathworks.com/help/supportpkg/beagleboneio/ug/use-the-beaglebone-black-spi-interface-to-connect-to-a-device.html (up to 32MHz) - which is
16 bits : is it possible to set all 16 pins on pru0 as inputs? I saw you mentioned something about disabling the microSD functionality on the BB to get access to all 16 pins, but I wasn't exactly sure how. -- heartofasquid I thought the PRUs had a 16bit parallel capture mode or are all the pins not available on the BBB? (need to consult the docs) section 4.5.2.2.3.2 of the tech ref spruh73c.pdf One thought I had was to use both PRUs to capture alternate bytes/words but that was just a thought, again are all the pins available? I'd made a mistake, it looks like all of PRU0's GPI pins may be available, if we are happy to lose the microSD (no big loss - there are other ways to get data in/out of the BBB). So, we can theoretically get high-res captures up to about 15bits, if we need 1 pin for the clock.

2015-12-04

BBB and 5Msps 12bit : a SO question
Registered at element14.com =)

2015-12-5th

Graphing all elements @GaiteLyrique
5 to 100 DC
- http://www.researchgate.net/post/Does_someone_know_an_simple_electronic_design_that_takes_small_PCB_area_producing_a_stable_100_DC_voltage_from_a_power_supply_of_5V2
- https://www.maximintegrated.com/en/app-notes/index.mvp/id/1751

Call/Chat Emmanuel - electronic board - 2 months is what he'd expect
Discussion S - review of scope / finetuning signals
- Necessity at 100V to separate HV to avoid interferences / noise
- Remark: using PRUs, we can go up to 50MHz (at least) from the ADC
Validation of parallel ADC
Mapping the Shield knowledge graph
Followup MIC

2015-12-06

Reflexions on documentation coming from this presentation on OSH
5Msps - Parallel - PRU up to 12 bits - can go further than 5Msps (SOA)
Buffer has to come (no, not the buffer app - real world buffer)
Thinking as well on architecture Motor + transducer + top in the probe Board + BBB (Node.js still..) * Output (if necessary)

2015-12-07

Busy business day
Usual monday meeting awesome progress on mech part. Seems robust, small, ... need to follow the power usage of POLULU ^^
What about a webcam video format? * WebRTC - awesome stuff at https://rtc.io/ for nodejs + webrtc

2015-12-08

http://www.theopensourceway.org/book/The_Open_Source_Way-How_to_tell_if_a_FLOSS_project_is_doomed_to_FAIL.html : nice doc to failproof a FLOSS project.
FPGA team
- FPGA vs µC : discussion ongoing with F&V - seems going towards RP. Sane, pragmatic approach. If the RP is cracked, that could unlock many things.
- Simulations to come from MIC
Another supplier
- seeedstudio.com(reco by F&V)
- See also http://pcbshopper.com/
PCBA abroad :
- myropcb
- nortechsys
- SeeedStudio only north america
PCBA in france:
- Quad Ind
- PCB-Pool
Fun on gerber and silk screens

2015-12-09

Following some design thinking classes for the sake of soft design & fun

2015-12-11

Update the Culture repertory in our drive :p
Piezo suppliers on their way
Mapping the DITSO resources - update
Apero !

2015-12-12

GP1A57HRJ00F // photo interrupter
Server for again 3 days...

2015-12-14

Holocracy progress
Comments from S: problems with HV system

2015-12-15

First elements from A - first draft (pdf file).

2015-12-16

Another feedback from S : small, interesting DC/DC power convertors from RECOM. Excellent idea.
Some great GIT cheatsheet - https://gist.github.com/mplewis/a7563c7cb589048a071b
The sysadmin apprentice : http://www.commitstrip.com/fr/2015/11/18/the-sysadmins-apprentice/

2015-12-19

S has started, on it

2015-12-20

Adafruit fun - display and printing ?
- Adafruit 1.8" Color TFT Shield w/microSD and Joystick: https://www.adafruit.com/products/802
- WIFI feather : https://www.adafruit.com/products/2821
- touchscreen : https://www.adafruit.com/products/1651
Thermal printing : https://www.adafruit.com/products/2753 but no level of grays

2015-12-22

Progress A / S
Caracterisation du piezo :

2015-12-27

Some PCB Assembly recommendation
- https://groups.google.com/forum/#!topic/tcmaker/rXdZSrWvRTU
- https://forum.sparkfun.com/viewtopic.php?f=20&t=36339
OSH Park, purple board, doesn't do assembly
https://macrofab.com/ -- GO FROM PROTOTYPE TO MARKET FASTER THAN EVER BEFORE -- excellent review

2015-12-28

Back from festive period ! But no slack:
- First iteration of A -- buffers as 74AC541MTC ?
- Schematics and BOMs from S
- Cacophony everywhere
https://www.youtube.com/watch?v=aPVLyB0Yc6I Eating bears
LCD at http://www.espruino.com/PCD8544
Autre display / TFT : https://learn.adafruit.com/1-8-tft-display .. et une micro SD integree =)
BBB headers : https://www.adafruit.com/products/706 (Stacking Header Set for Beagle Bone Capes (2x23) @5$)

2015-12-29 Some ada news

News

vieux displays: https://www.adafruit.com/categories/99
https://www.adafruit.com/product/358
https://www.adafruit.com/products/2478 : 240by 320 screen, touch, sd
- The display can be used in two modes: 8 bit or SPI. For the fisrt you'll need 12 lines total. Second mode requires only 5 pins total but is slower than first.
- In addition, 4 pins are required for the touch screen (2 digital, 2 analog)
- Tuto : https://learn.adafruit.com/adafruit-2-4-color-tft-touchscreen-breakout
https://www.adafruit.com/products/1480 : 320 by 240 screen, 4-wire SPI to communicate and has its own pixel-addressable frame buffer
- Seems like the BBB SPI communication rate are around 0.1s to draw the image over SPI.. may be a tad slaw to only display an image

Bots

Onboarding bot for Slack at https://18f.gsa.gov/2015/12/15/how-bot-named-dolores-landingham-transformed-18fs-onboarding/ (in ruby)

2015-12-30

Did automatic backup for the wiki, for the migration - yeahhh
Smartassthoughts
- The absence of deal-breaking flaws is more important than the presence of any extras. You don’t need anything special to succeed. You just need to do the essentials properly.
- Power is like being a lady… if you have to tell people you are, you aren’t. -- MT
FTS
Don't forget spider jerusalem's example - bards, journalists, and a merry cacophonic 2016

2016-01-06

Trial on PCBCart
Render of the Murgen 1.0 board

2016-01-08

Small adjustments from the questions raised by PCBCart

2016-01-11

Completed the S project -- CLOSED ;)
The A project is ongoing

2016-01-12

Kelu124 back in France

2016-01-15

Boards:
- Confirmation that Seeedstudio does not ship out of north america
- Getting other options and quotes from Advanced Circuits, Macrofab (awesome interface), PCB Pool.
Need for a filter to get be sure , there's a low frequency component that remains: to remove- and to center around 0V ?

Let's cut it to 500kHz ?

For headers, we have
- 12 input pins on P8 for PRU1 and 1 input pin for PRU1 on P9, these have been assigned for 12bitADC+Clock and the rest,
- SPI for DAC,
- Buffer enable and motor control have been assigned to PRU0.
For the controls in prototyping:
- SW1 controls the gain range for TGC
- SW2 controls the input range of the ADC,
Updating the blog as well, integration of disqus

2016-01-16

disqus working
creating something on makake.. but seems bugged at the moment
list of components on the blog
discussions with edgeflex (thanks flylabs!) and macrofab (fun, and willing to test a 4 layer project in beta - only working in 2 layers so far)
work with S to integrate a high pass filter (1MHz+) following the echo on Jerome's hand
Follow up with Charles
- working on the RP with a student
- exploring collaborations

2016-01-18 Testing stuff

Call with Edgeflex
Breakout boards for SMDs :
- https://www.adafruit.com/products/1210 / https://www.adafruit.com/products/1206 / ...
- https://www.adafruit.com/products/1281 to test
Followup with Macrofab
Producing the XYRS from Altium
Starting mini board - board #2 -- what name (if not murgen, Tobo ?)
Order for a ThermalPiPrinter :)

2016-01-19th

Slight tweak of the budgetting for engineering a probe :) we have this GDoc

2016-01-20

What about having a µC ( PIC24FJ128GC010 ?) right after the analog part - could be an additional board/cape stacked below (so with microcontrolleur and alimentation)
- it would stream data like a wifi camera
- receives the ping from the motor controleur
should we be ordering SMD stuff (flux, fer à souder, soufflerie?) - seems an idea
Creation des modules !

2016-01-21 Site changed

Changed WP template to something more readable
Post on HN .. even went 2nd :)
Awesome work from Farad

2016-01-22nd

Updated the GitHub Readme.md (still lacking a pic, damned!)
Outputs from the HN post
- 3700 visitors in less than 20 hours
- Interesting comments at https://news.ycombinator.com/item?id=10944617
- Interesting contacts (anfractuosity - leptitg )
- Interesting page : https://www.anfractuosity.com/projects/hardware-development-links/
TODO : get something on reddit ?
http://finda.photo/#v2 TOF en CC0

2016-01-23 On Oreilly

Murgen on http://radar.oreilly.com/2016/01/four-short-links-22-january-2016.html
Prez done here
Awesome boost on github and the wiki
adding some to the documentation @done : need to get to read more the TAPR and the full license http://www.tapr.org/TAPR_Open_Hardware_License_v1.0.txt @done : add CONTRIB.TXT and CHANGES.TXT
@cld : failproof OSH

2016-01-24 Datasheets on Murgen

added datasheets
@done : think about a USB/BT/... output for the board - see matty
Output ? What format? USB - but I'd rather have wireless ? Wi-Fi Direct promises device-to-device transfer speeds of up to 250Mbps

2016-01-25 Tobo gets born

Tobo is born ;) as a goodie/bonus for murgen
Some resources (thanks Oliv' =) ) http://www.evilmadscientist.com/2011/improving-open-source-hardware-visual-diffs/ https://opendesignengine.net/ not working at the moment
Repos work Github hooks: https://github.com/icefox/git-hooks what's http://www.solderpad.com/ worth ?
Reading : http://opensourceecology.org/wiki/Open_Design_Engine
FUN USB keyboard emulator : http://www.instructables.com/id/USB-PCB-Business-Card/

2016-01-27 Releases on GH

GitHub signing a release :
- Howto : https://wiki.debian.org/Creating%20signed%20GitHub%20releases
- Creating a key http://ekaia.org/blog/2009/05/10/creating-new-gpgkey/
Hardware:
- PCBs have been ordered, 3 days to come.
- 1st and 2nd boards on their way.
TODO: sign a release as soon as some code is on the way

2016-01-29 Versionning

http://semver.org/ for semantinc versionning of releases

2016-02-13 Release of Gob

Lots under way..
- - Required : we need to sit with electronics experts to check how Murgen, Tobo, Goblin, and Mira can merge - for a modular board - ideally as easy as possible to use!
IDEA: capelec!
Need also to push Goblin's files on the repo. Those are made with Eagle, not Altium, so a bit less options, but still interesting to see how to work with those files =)

2016-02-15 Lit review

Was about time I got some serious litterature review :)

http://sci-hub.io/10.1109/ULTSYM.2015.0517 for a full fledge Smartphone Probe =)
Microcontroller USB interfacing with MATLAB GUI for low cost medical ultrasound scanners

Some others

Integrating hardware and software for the development of microcontroller-based systems
IDEA: Design of a USB based multichannel, low cost data acquisition system using PIC microcontroller

2016-02-16 Jatin work

Waiting for the board ;)
Awesome work : Development of a wide band front end echo sounder receiver circuit by Jatin Sharma ( definitely need to contact him)

2016-02-17 Steppers

Fun hardware:
- IDEA : Good stepper: 99$ / https://www.pololu.com/product/2294
- There are cheaper steppers on Lextronics (+driver)
- Pololu - LP 6V Motor with 48 CPR Encoder for 25D mm Metal Gearmotors (No Gearbox) (https://www.pololu.com/product/2280 )
- https://www.pololu.com/product/2213 for a small motor
3D models of RPi, BBB:
- BBB: https://www.thingiverse.com/thing:920804
- RPi: http://www.thingiverse.com/thing:278113

2016-02-18 Reads and random stuff

Interesting read at http://wp.josh.com/2014/03/03/the-mystery-of-the-zombie-ram/ !!
Discussions on mechanics =)

2016-02-19 Dispalys

IDEA : display : 128² OLED screen: https://www.adafruit.com/products/1431

2016-02-21 Links et al

Asking feedback from M. Cooke
http://sci-hub.io/10.1109/ULTSYM.2013.0526 for Smartphone-based Portable Ultrasound Imaging System : A Primary Result .. can't manage to reach them.
ebay :
- Aloka ASU-66 -- http://www.ebay.fr/itm/Aloka-ASU-66-Ultrasound-Probe-/221690345989?hash=item339dc63a05:g:l~gAAOSwBLlU3n1H
- Aloka ASU-32H-3.5 Mechanical Probe -- http://www.ebay.com/itm/Aloka-ASU-32H-3-5-Mechanical-Probe-/190660257677
- ATL-ADR-5-5-MHz-7-mm-Ultrasound-Transducer-Probe-for-UM-4-7081
- ATL Access 10PV is a sector array ultrasound transducer probe. The ATL Access 10PV is a mult-frequency probe with a range of 5.0, 7.5 and 10.0 Mhz. -- http://www.ebay.com/sch/i.html?_from=R40&_trksid=p2047675.m570.l1313.TR0.TRC0.H0.XATL+Access+10PV.TRS0&_nkw=ATL+Access+10PV&_sacat=0 * * AWESOME* *
- IDEA : mechanics design idea !
- Same for ATL Access B10
- All * * ATL Access* * aaahhhh
  - ATL-Access-C-3-0-MHZ-12-7mm-dia-Ultrasound-Transducer-P-N-101-25909-72-3862
- GE Kertz Technik S-VNA5-8 Transducer

2016-02-22 FPGA interface

IDEA : interfacing murgen with a FPGA ? Solution here : store.hackaday.com/products/xula2-lx9
IDEA: doing a probe emulator? Signal generation upon a pulse transmitted : a physical emulator for the probe head =)

2016-02-23 passphrase whats thats

Passphrase.io seems interesting =)

2016-02-24 Wifi and ESP8266

What can we do with wifi / ESP8266 // http://makezine.com/2015/04/01/esp8266-5-microcontroller-wi-fi-now-arduino-compatible/ ?
http://darksearch.io/ is fun ?
No stuff - https://sivers.org/gifts in favor of it =)
Some news from Amit

2016-02-25 Shorts

Boards reached: issue with the 5V and GND - shortage

2016-02-26 More about shorts

Further tests. Shortage still exists.
- Short is not on the PCB. Appears after solder.
Found that the RECOM component was designed to be upside down -- need to resolder it. Luckily it was a via component.
- This would not be the source of the short anyhow.
- EF recommends that we burn 10A on the 5V plane to see which component would burn.. hmm i'm quite shy to do this :p
Documenting the issue on github.
Sending back boards to EF.

2016-02-28 Admin reports

Starting the interim report.

2016-02-29 Short source

Found the source of the short, ADL5511, 5V and GND inverted...
- TODO : amend the altium files to correct the ADL5511 and the RECOM tracks
TODO : sampling freq to be documented

2016-03-01 Boards sent back

Sending back the boards

2016-03-03 Digging into BBB

Receiving new, corrected boards
SO qusetions to be tapped into?
- http://stackoverflow.com/questions/35681099/beaglebone-black-control-gpio-with-pru
- http://stackoverflow.com/questions/35747954/beaglebone-move-data-from-pru-to-ddr-ram
Newscastle published something new on their mechanical probe, awesome!! http://www.ncl.ac.uk/eee/research/groups/coms2ip/ultrasound-imaging.htm

2016-03-04 Tests of the boards

Testing the board on the morning

## 2016-03-06 Hacking on hackaday

Posts about the day hacking at
- https://hackaday.io/project/9281-murgen/log/33275-getting-the-first-echoes
- https://github.com/kelu124/murgen-dev-kit/blob/master/Session_1.md

2016-03-07 Diverse stuff

HackerNews : https://news.ycombinator.com/item?id=11232144
Matos
- Inverseur : CD74HC4049E
- Caps 1.27mm
  - M50-1900005
  - M50-2020005

2016-03-08 HV7360 how to use it

GSCholar pour HV7360 (to solve the issues) : 10.1109/ULTSYM.2015.0140
HV7361 : Sharma
TODO
- Pulser: integrer un schema sur le readme de murgen
- VPE est a 5V sur notre board - 3.3 en typical. Logique à remonter?
- Add a resistance in parallel of the transducer?
Damn!! The alimentation voltage was low... because it takes 6.5V to 12V! Will need to put 9V in through the thermal printer alimentation

2016-03-11 Pulsing and al

Session 2 : Non-controlled pulsing, inverters, better echoes

2016-03-14 First echoes

Starting to get echoes

2016-03-15 Controlled pulsing

Session 3 : Getting controlled pulsing, but width not controlled

2016-03-18 Charles gets in action

Sending his board to prof Charles

2016-03-19 Testing with a transducer

Session 4 & 4b
- Testing the board with the transducer
- Testing with the BitScope

2016-03-20 Getting the first images

Getting the image!
- Assembling everything
- Coding in python
- Thanks bitscope

2016-03-21 Doc again on HAD

Doc
- Documenting on hackaday: visit, by all means, that's cute and nice!
- Same documentation on the github repo
Modular design in on with Benoit ! Let's check with Sofian
TODO:using SPI on the board
- plugging a SPI
- pluging the pulseroff in the buffer part?
TODO:logo of murgen in vector

2016-03-22 Questions and asso

PENDINGTODO
- print and distribute the interim report
- Organizing elections for the association
  - Define responsibilities of all
  - Review of les status de l'association
  - Review of the reglement interieur
- Definir who has access to the twitter account
- Wiki delivery
- Documentation
- BM's gerbers, altiums et al
- Costing of mira
- License issue on the wiki
- Budget update - what do we have?
- Project forecast - where do we go?
- Restructuration du wiki
- Page de veille a mettre sur le wiki
- Creer une page competition
- Traiter les "objectifs" de la fondation fabre et les finir
- Gerer les cotisations, faire un appel à cotisation
- publier les soutenances de F&V?
Some SO questions:

2016-03-23 Challenge page created

A challenge page was created
- working on modules =)
- thinking of the motherboard (contribution of benoit)
- Enveloppe detection

2016-03-24 Demoing day

AOP (high speed 420MHz) THS3001 (Amit)
TODO:
- MFab - plan
Presentations tonight!
Getting good echoes with the TGC maxed!
Playing with bitscope / issue from the noise / usb plugin got !

2016-03-29 Noise and noise

order for the usb denoiser
http://www.st.com/web/en/catalog/mmc/FM141/SC1169/SS1576?sc=stm32f3 : Getting 5Msps =)
Farnel price bitscopes
- http://uk.farnell.com/bitscope/bs05u/oscilloscope-logic-analyzer-2/dp/2432906: 59£ (73€) (HT?)
- http://uk.farnell.com/bitscope/bs05p/oscilloscope-adaptor-2ch-20mhz/dp/2455593 : 89£

2016-03-31 First phantoms

Doing some new fantoms
Receiving the AFORP's guys

2016-04-01 Pulses with pi

Generating pulses with RPi : http://codeandlife.com/2012/07/03/benchmarking-raspberry-pi-gpio-speed/ -- up to 22MHz
Sofian's back ;)

2016-04-03 Cleaning first images

Cleaning the acquired images
4T scan conversion algo OK and working

2016-04-05

TODO: creer les liens sur le software/readme vers les fichiers sources

2016-04-07

trying some docs at https://github.com/kelu124/murgen-dev-kit/blob/master/hardware/doc/murgen-dev-kit.markdown
starting with the modules..

2016-04-08 Nice reads and al

Nice reading =)

Basecamp outlines their goals -- which they say have always been the same -- on their website:
- Have fun
- Do exceptional work
- Build the best product in the business
- Experiment
- Pay attention to the details
- Treat people right
- Tell the truth
- Have a positive impact on the world around us
- Give back
- Keep learning.
"We’re also big believers in business 101. We don’t spend more than we earn, we don’t waste money on things that don’t matter, we don’t give away everything for free and hope we’ll figure it out before we run out of cash. We’re in business to stay in business, and we have 15 profitable years in a row to back it up."

2016-04-09 Some reads about PRUs

Some reads on PRUs:

2016-04-11 Microcontrollers choices

Choice of a uC: "le boulot des microcontrollers, ce qui me gene sur l'espruino c'est le manque de sortie wifi - si on veut sortir des donnees en wireless." Deux choix se profilent

WICED : STM32F205RG 120MHz ARM Cortex M3 MCU : 17 timers et 3 × 12-bit, 0.5 μs ADCs with up to 24 channels and up to 6 MSPS in triple interleaved mode, 8- to 14-bit parallel camera interface (48 Mbyte/s max.)
Le WifiMCU : EMW3165 : M4: STM32F411CE @100MHz, DSP+FPU, 1×12-bit, 2.4 MSPS A/D converter -- Ce qui me fait peur est un WifiMCU de base en LUA, a voir comment repasser sur du plus bas niveau. L'avantage par contre c'est qu'il est dispo chez hackspark, et coute 18€ au lieu des 35$ du WICED =)

Remarques : Avec le M3 tu perds les instructions DSP et un FPU optionnel (cf https://en.wikipedia.org/wiki/ARM_Cortex-M). Par contre je ne sais pas si c'est correctement exploite, ni si on en a vraiment besoin.

Il y a aussi le Module Particle "Photon" http://www.lextronic.fr/P37394-module-particle-photon.html (M3 120 MHz et wifi) ou l'Arietta http://www.lextronic.fr/P32050-module-microcontrole-arietta-g25.html

Apparament module ferme

Worklog -- Starting April 5th 2016

2016-04-05 Captech

Validation of the approach by the Captech

2016-04-08 Tracks of interest

Validation of tracks of interest

2016-04-15 Tracks

Validation of tracks and their orders
Alexandr

2016-04-16 uC

Studying microcontrolers... See microcontrollers

2016-04-17 PCB

Getting a first design for the pulser module

2016-04-18 ADL5511

Playing a bit with ADL5511 : there's an EREF
We use offset remover (suiveur + gain de 2.5), and second op will do amplification, cause envelope output swing is saturated at 1.2-1.3V, We can use 2..2,5 gain to deliver nice and neat 2,6 ..3V input swing for ADC.

2016-04-20 Modules

Previous Generation

Murgen : the annalist.. already done, a former project !

Current batch

Goblin: the analog heart, was drafted as well during Murgen.
Tobo: the HV/pulser, based on a drafted close to Murgen.
One-Eye: MicroControler - Arduinos
Mogaba: Alimentation

Second generation of fun! Learning microcontrolers and advanced simulations

Croaker: M3/M4 microcontroler
Silent : physical emulateur

2016-04-23 Servos

A stepper based on a servo : https://hackaday.io/project/11224-mechaduino (pour @bivi)

2016-04-24 Maintainers

Starting to document Tobo
Reading "Maintaining Open Source Projects" by Tute Costa : A project maintainer should feel comfortable shaping the community, promoting the library, keeping good communication with different people, deciding when to release new versions, and prioritizing all these tasks.
Getting a TL-MR3040 TP-Link for a project PirateBox (an echObox ?)
2016 strategy being done

2016-04-25 Working IRL and motivation

http://bengarvey.com/2016/04/24/real-work/ How many times today did a customer notice something you did?
http://www.stubbornella.org/content/2013/02/26/why-i-run-my-business-like-an-open-source-project/
http://www.atlasobscura.com/articles/the-rise-of-illegal-pirate-libraries?utm_source=facebook.com&utm_medium=atlas-page

I define Real Work as

Work that creates an immediate and positive change in your product/service
Work that is a direct constraint to the completion of A
Work you have been uniquely hired to do.

2016-04-26 Motivation

"I am not a visionary, I'm an engineer," Torvalds says. "I'm perfectly happy with all the people who are walking around and just staring at the clouds ... but I'm looking at the ground, and I want to fix the pothole that's right in front of me before I fall in."

2016-04-27 Documenting

Meetings (virginie)
Doc of modules : https://github.com/kelu124/echomods/
Preparation of Testing tools for the doc
Materials : some awesome resources : Il existe des tables sur les plastiques (http://www.ondacorp.com/images/Plastics.pdf) et autres caoutchoucs (http://www.ondacorp.com/images/Rubbers.pdf ) mais rien de concluant (ref, eau a 1.5MRayl). Il y a des choses comme le Polyurethane, RP-6400, a voir.
Documentation echomods
Premier module OK : (HV, + pulser) sources publiees (same github), fab-ready, quasi documente
Deuxieme module OK : (TGC, Enveloppe, ADC) sources publiees (same github), fab-ready, documentation en cours

2016-04-30 MBTI and DDS

Am an INTJ-A ... so what?
R-2R DDS -- =) MHz DDS with arduino ?
http://www.tek.com/blog/tutorial-digital-analog-conversion-%E2%80%93-r-2r-dac
https://hackaday.io/project/9469-misc-arm-projects/log/31489-quick-dirty-dds-for-around-1

2016-04-29 Some stuff

Fun to read

NT: The evolutionary argument against reality.
Beard things...
Autodocumenting with makedoc.py - which updates the Readme.md automatically.

2016-04-30 Graphs

Adding graphs for all modules with makedoc.py.
TODO: https://www.coursera.org/course/fin4devmooc
TODO: https://www.coursera.org/course/effectiveppp
TODO: https://www.coursera.org/course/healthcareinnovation

2016-05-01 A bit of work

Done: TOBO and GOBLIN
Done: Autodocumentation
Comment gerer les transducers de Jan?
Projet Fantomes commence sur HAD : phantoms are starting to appear on Hackaday
http://electronics.stackexchange.com/questions/50577/what-ultrasonic-sensoremitter-should-i-use-for-my-medical-ultrasound-project
http://electronics.stackexchange.com/questions/129582/what-is-the-current-consumed-by-ultrasonic-sensors-transducers-1-2mhz-to-gener?rq=1 for power use

2016-05-02 What

http://uk.businessinsider.com/interview-with-estonia-cio-taavi-kotka-2016-4

2016-05-03 Max Hold Reset

http://hackaday.com/2016/04/29/saving-lives-with-open-source-electrocardiography/ Max-Hold-Reset
https://fr.wikipedia.org/wiki/Circuit_d%C3%A9tecteur_d%27enveloppe -> Schema a amplificateur operationnel (peak detector)
http://electronics.stackexchange.com/questions/112347/how-to-make-a-peak-detector-circuit ou peut etre encore mieux :
http://www.planetanalog.com/author.asp?section_id=396&doc_id=562072
Got it !! http://www.falstad.com/circuit/e-peak-detect.html
ESP8266: exploration: SPI-ADC+ESP.overclocked ? : http://stackoverflow.com/questions/37014547/esp8266-and-high-speed-external-adc

2016-05-04 May the fourth

2016-05-07 Websocket

https://forum.pjrc.com/threads/34095-Teensy-3-2-ESP8266-12Q-High-Speed-ADC-Websocket

2016-05-10 KiCAD

https://contextualelectronics.com/gtb-kicad-4-0/ : 10 Part Tutorial On Designing/Building A PCB (Using FOSS)

2016-05-14 Work in Indonesia

Off to Jakarta =)
Next prios : Feather and ESP8266

2016-05-23 Transducers

Restarting work with transducer and boards makers, Jan and Jerome

2016-05-24 RPi

Bass inspiration : https://www.youtube.com/watch?v=6ZDTelKz4G0
Working on Raspberry Pi Zero notes
Updated existing notes on microcontrollers and the ESP8266
Thinking about video / photos port to raspberry (even better than USB transfer, it manages quite high speed ( The two data lanes on the CSI-2 bus provide a theoretical 2 Gbps bandwidth, which approximates to around 5 MP resolution. ) here

2016-05-25 Markdown and downs

http://stackoverflow.com/questions/4823468/comments-in-markdown
Article on Projects http://teambit.io/blog/all-your-teammates-will-be-gone/
www.theatlantic.com/health/archive/2014/06/the-dark-knight-of-the-souls/372766/
http://www.certwise.com/blog/31-ways-know-project-doomed/
http://gettingreal.37signals.com/toc.php

2016-05-27 Partenariats

Exploring the partnerships with J&J

2016-05-30 ESP and such

http://www.esp8266.com/viewtopic.php?t=669&p=3624 HPSI on ESP8266
Nicolas from V.
Lancement des PCBs (Jerome)
Go for Piezos (Jan)

2016-05-31 Hackaday fun

Redirection de visiteurs de Hackaday vers nos ressources
Reflexion sur l'EMW3165 -- 8$, ADC à 2.4Msps, WiFi.
Extraction de la connaissance à partir du BC3: petit souci, le contenu BC3 ne semble pas exportable (pas de dump possible comme avec BC2), et n'a pas d'API d'integration.
Petit truc sympa, mais pas encore sorti : un SoC pour le RPi : https://hackaday.io/project/11981-rppsoc-system-on-a-chip-for-the-raspberry-pi
Pas possible de créeer le Wall of Contributors, tjrs ce probleme de reset de mot de passe, aucun email n'arrive.
TODO: réorganiser les Readme entre echomods et medicotechnical et leur prod automatisée =)
EMW3165 : "All I see is an under 8 USD STM32F411CE dev board with some wifi gadget" ( http://www.emw3165.com/ )

2016-06-02 Some awesome OSH for medical issues

An endoscope pill

What about XRays?

And CT Scanners?

and MRI ?

https://hackaday.io/project/5030-low-field-mri

and *CG ?

2016-06-04 Learning more on STM32

Note d'application des timers par STM
Un très gros bon post sur les timers : un mois de travail d'après l'auteur - post de blog
Et son petit frère sur les ADC
Getting comments on scan conversion at HAD

2016-06-06 Weekly monday

Weekly meeting at the HD
Prof Charles and Zach start playing with Murgen, so I'm starting to experiment with Jekyll for murgen on the corresponding Github murgen page

2016-06-07 Hall of fame

Getting a copy of an excellent book : buy here
Reading more about open science hardware with GOSH.. and finding a good OSH journal which leads to there : http://www.journals.elsevier.com/hardwarex
Awesome DIY approach and techniques for ultrasound gel -- already republished on HAD

2016-06-08 Zach

Semifinalist for HACKADAY's challenge !!
lending a hand to Zack on GitHub et al : https://github.com/ZTaylor39/murgen-dev-kit
Interrupts on Arduino for the emulator : https://learn.adafruit.com/multi-tasking-the-arduino-part-2/external-interrupts

Some research on DACs:

DAC0800LCN 8-Bit D to A Converter -- http://www.makertronics.co.uk/images/detailed/5/Ext-2254-010.jpg?t=1437747336
http://forum.arduino.cc/index.php?topic=179410.0
http://www.ti.com.cn/cn/lit/ds/symlink/dac0800.pdf
http://hackaday.com/2011/02/17/your-first-digital-to-analog-converter-build/
Example : https://labarqui.wordpress.com/2012/07/03/emulador-de-notas/

R2RlLadders

2016-06-09 Week end !

And nothing.

2016-06-13 News

Moving forward with Zach
Creating a 8 bit R2R resistor ladder

2016-06-14 Super hacks!

Discussion engaged with Muth (et son pi-print) for a thermal printer addon
This hack of a eink display is awesome. Hacking a STM32F103ZE and plugging a ESP8266
Working on CSV images library for images using the CSV+dict format

2016-06-17 Printing and budgets

Printing with the thermal printer: a success with https://learn.adafruit.com/networked-thermal-printer-using-cups-and-raspberry-pi/network-printing
No news from Zach ?

Shopping à faire: 1000$ = 840€

RPi0 : 42€
Lulu - book on opensource projects : 17€
Work on EMW3165: 230€
Transducteur : 150€
Matos en rab EdgeF: (125€)*3/4
Deux modules echomods : 110+140 (-125/4)€
Reste: 101€ for contigencies + SMA cables + matos (bois)

2016-06-18

Awesome CapMED
Retroengineering a 10PV probe.. only 10PV? Ain't much.
Drinking beer
Admiring an IA work at recontructing blade runner

2016-06-19 Hmm

Followup with Zach
Ping Michael T
Ping Edgeflex: quid microcircuits

Beaglebone black : Max SPI 32MHz

Available probes, one of which being a 10PV:

2016-06-21 Financing

2016-06-22 Slides, and VDB

Resources sympas : http://bafflednerd.com/learn-python-online/
http://pandoc.org/README.html#producing-slide-shows-with-pandoc

2016-06-24 Mechathon

Working at the mechaton at the CRI
Playing with Zach's acquisition and testing his filters
Processing!
Old.. mais retrouvé: https://web.archive.org/web/20151204121552/http://www.ncl.ac.uk/eee/research/groups/coms2ip/ultrasound-imaging.htm

2016-06-27 Nothing new

Discussion with NF@V -- interesting. Could be partnering for some cool ideas. Vets, hackers. Maybe soon for docs.
Has contacts with electronics experts
Tests of transducers by Jerome

Some ideas on RPi and SPI:

2016-06-30 Recycler un minitel

Pour recycler un Minitel, ca se passe la

2016-06-30 New probes et al

Deux sondes d'occasions assez sympa pour démontage et analyse (mécanique / materiaux / piezos):

IA and US:

http://sci-hub.cc/10.1109/TBCAS.2015.2431272

2016-07-01 Meeting with Nicolas

Terribly instructive. Lots to learn.

2016-07-02 Strategy

Just doing it!
Key learning: will be having fun soon =)

2016-07-03 Playing with a trifrequency probe

Won the probe http://www.ebay.com/itm/Philips-ATL-Access-A-3Mhz-Ultrasound-Scanhead-Transducer-Probe-/262496926313?hash=item3d1e093a69:g:psAAAOSwcL5XMe0n (50$) -- that's a purely 3MHz probe, should be OK and we won't get too many issues with too high frequencies
Played with the ATL10PV at https://github.com/kelu124/murgen-dev-kit/blob/master/worklog/Session_9_ATL.md. Not good results, high frequency elements are buggy.
Any impact of the polarity of the pulse??
TODO: Compare the polarity by switching polarity.

2016-07-04 Meeting

Long one, instructive. *BBB : https://groups.google.com/forum/#!topic/beagleboard/3AFiCNtxGis and https://www.element14.com/community/external-link.jspa?url=http%3A%2F%2Fhipstercircuits.com%2Fbeaglebone-pru-ddr-memory-access-the-right-way%2F
Digging into https://developer.mbed.org/platforms/LPC1114FN28/: a DIP M0

2016-07-05 RTL-SDR

Bivi's playing with RTL-SDR.. a simple short and one can get to the 0-30MHz, without any upverter. Fun. To explore.

2016-07-06 Making progress with EMW3165

With the help of Igor, preparing a UDP server of EMW3165 and getting a throughput of 9Mbit/s on average.
Getting one of the modules
Requesting Nicolas' help on getting HV7360LA (fab's suppliers are lost)
Thinking of the overall structure of the maker kit. I need a wooden box and an aquarium (plexiglass, glue = solvent cement)
Review of the HAD budget (probe, transducer, fab, et al?). Some euros may be saved.

2016-07-08 ATL Probes, ebay & WiFi

Other ATL Probes:

The ATL manual is available at : http://photos.medwrench.com/equipmentManuals/4692-2615.pdf (see copy in the 10PV folder)

EMW3165 and SPI:
http://www.emw3165.com/viewtopic.php?t=4330&start=10 or (3$ http://www.ebay.com/itm/131627127638?_trksid=p2057872.m2749.l2649&ssPageName=STRK%3AMEBIDX%3AIT )
TODO: some shopping on ebay
http://www.ebay.com/itm/SPI-IIC-MPU-9250-9-Axis-Attitude-Gyro-Accelerator-Magnetometer-Sensor-Module-/131185485892?hash=item1e8b43a844:g:qXkAAOSwuzRXdx-~
http://www.ebay.com/itm/NodeMcu-Lua-ESP8266-CH340G-WIFI-Internet-Development-Board-Module-/161833537754?hash=item25ae07d0da:g:N-4AAOSwepZXSUtI
http://www.ebay.com/itm/Arduino-Shield-40pcs-20cm-male-to-female-Dupont-cables-/140741253413?hash=item20c4d51925:g:uSMAAOSwMNxXYPH7
www.ebay.com/itm/Mifare-RC522-Card-Read-Antenna-RFID-Reader-IC-Card-Proximity-MFRC-522-Module-/130892542303?hash=item1e79cdb15f:g:3h8AAOxycERRjRN7
http://www.ebay.com/itm/84-48-LCD-Module-White-backlight-adapter-pcb-for-Nokia-5110-top-S3-top-good-sale/172260052269?_trksid=p2047675.c100005.m1851&_trkparms=aid%3D222007%26algo%3DSIC.MBE%26ao%3D1%26asc%3D20131003132420%26meid%3D836a21703127491d9ad58909aad4acab%26pid%3D100005%26rk%3D1%26rkt%3D6%26sd%3D131739821242
http://www.ebay.com/itm/2PCS-2-4G-Wireless-SMA-Antenna-2dB-2-5dB-Gain-for-NRF24L01-PA-CC2500-Module-/161987106053?hash=item25b72f1505:g:VkIAAOSwMN9XQ8id
Awesome TFT screen -- really cheap: http://www.ebay.com/itm/131627127638?_trksid=p2057872.m2749.l2649&ssPageName=STRK%3AMEBIDX%3AIT

2016-07-09 Goblin works !

See the github repo for goblin. worked on the doc

2016-07-10 Should be doing some queries on Alibaba..

TODO: Getting samples and suppliers ?

2016-07-11 Getting a first transducer

Got and paid for a SM heavy backing transducer. Now, let's find what servo to use.
TODO: servo + transducer + mounting platform

2016-07-13 Some new stuff

SPI
https://learn.sparkfun.com/tutorials/raspberry-pi-spi-and-i2c-tutorial
essayer SPI avec les petits trucs funs
cables pour SPI a base de cables ethernets?
STM32: mise a jour du fichier uC avec un nouveau STM32 dans Notes uC
Contact AD

2016-07-15 Playing at the lab

Cleaning a signal with Goblin : done. The second log, with this time a new energy supply, gives a really beautiful outcome. Lesson: don't put 18V in a 3.3 and 5V regulator =) See the results here.
Playign with an ATL Access 3. Getting nice echoes... of 1.3V, even not using the full gain (60%) and the full pulser voltage on Murgen. See the logs here. Was some work with the oil refill =)

2016-07-17 ATL probes

Finding more about ATL probes - with a list of probes, and trying to find back the pins!
TODO: Presentation on Goblin's module

2016-07-18 Some goodies

Cheap ATL Access Probes
Finding more about ATL probes - with a list of probes, and trying to find back the pins!
Autodocumenting -> See the results of autobuilding doc at : https://github.com/kelu124/echomods/blob/master/Readme.md. None of it is written by hand.
Read also an ... autogenerated prez about this here.
This post blog is also autogenerated using the worklog..

2016-07-19 Plenty of stuff

Passionnant: https://hackaday.io/project/11943-open-indirect-ophthalmoscope
Récupérer la datasheet : http://www.analog.com/media/en/technical-documentation/data-sheets/AD7276_7277_7278.pdf
Cf Baptiste Pierrat - https://e2e.ti.com/support/arm/sitara_arm/f/791/t/396940

BBB->Baptiste Pierrat->FastPRU->UpTo3Msps

Initialiser PWM sur un trinket pro : https://learn.adafruit.com/introducing-trinket/programming-with-arduino-ide

TODO:

Base sonde

Finir de remplir d'huile la sonde
Tester les connections du BBB, déterminer les masses, surtout trouver le moteur
Faire des acquisitions a full speed avec Murgen+Bitscope

SPI et BBB

Tester le SPI avec BBB (Baptiste Pierrat)
Si ca marche, tenter de controler Moteur + Pulser avec BBB

2016-07-20 Murgen on the way for the second prize!

Reponse de Baptiste Pierrat
http://hackaday.com/2016/07/18/hackaday-prize-20-projects-that-make-us-all-citizen-scientists/ =) Yeaayyy merci pour la reconnaissance =)

2016-07-21 Next steps

Working on a presentation for the next steps of these modules
Envoi a edgeflex d'un HV7360
Hellyeah : http://www.cnx-software.com/2016/07/21/google-research-prudaq-is-a-40msps-adc-data-acquisition-daq-cape-for-beaglebone-black-green/

2016-07-27 Apres Avignon

Yeayyy! Beagleboard fondation tweeted about Murgen -- that's driving traffic to github =)

High speed acquisition

PRUDAQ

Slow Acquisition

tobo/goblin+cletus+BBB to drive the goblin ADC
tobo/goblin+cletus+hannin to wirelessly stream

I decided the emulation was going to be necessary to avoid playing all the time with piezos. It appears Teensy 3.2 can handle that.

Choice of the servo:

More stuff about Phantoms: http://meritus.kopernika.pl/homemade-tastes-better/

And ... working on the 2016 Summer presentation.

2016-08-02 Last week, after a week holiday

Working on the milestone presentation.
Received a 12V alim, the PRUDAQ, and pushed the issue with Silent onto github. Ongoing !

2016-08-04 Soon off

Working on the finance file --> still work to do !
Setting the stuff on for 1000$ from HAD
HD should have received the pulser module.. waiting for it =)
Worked on the doc-test script to automatize the results of modules documentation tests -- see an example with an error

2016-08-08 First day

Received tobo !! yeayyy
Playing with Doj and assembling the board (tobo, goblin, oneeye and mogaba). Should be enough to get first images.
power seems OK, first pulses look nice
Todo: test with my transducer for Cletus, and with ATL3
Thanks to Virginie for her support on debugging Doj !!

2016-08-09 Moving forward

Roughly, all the modules are fine. Emulator is done and tested. Some tests today:

Test Analog Processing + ATL3
- -> https://github.com/kelu124/echomods/blob/master/goblin/2016-08-09.md
Test Emulateur de signal + Analog processing
- -> https://github.com/kelu124/echomods/blob/master/silent/Readme.md

What the next steps are :

High priority:

Use PRUDAQ
- Clip the signal between 0 and 2V
Get image from the retroATL3

Medium Priority:

Bitbang Goblin's SPI directly
Resume documentation

Low Priority:

EMW3165 to move forward
Cletus for Servo + Piezo (and mech parts) - using SmartMaterials piezos

2016-08-10 Simple things

Clipped the signal
Documentation ongoing
Received TFT+Servos

2016-08-11 Small FPGA

Awesome work: a FPGA on a RPi0 footprint

https://hackaday.io/project/13048-fleafpga-ohm-development-board

2016-08-14 Acquiring a first image

Read some on this page: got an image from a ATL3 probe, a small metal cube in water.
Leaving for holidays =)

2016-08-22 Back from holidays

Working with Virginie and Benoit to get images
Got to play with a general multi tissue fantom: got an image from a ATL3 probe, of the fantom.
What about using Kaggle as a data repo for open data ?

2016-08-24 Finalizing the autodocumentation to gitbook

Yeay!! Done. Gitbook available on this page

2016-08-26 Show and tell

Showing the documentation generation process on an apero at l'Hotel Dieu

2016-08-28 Sharp eye

Thanks to a question raised by a sharp-eye, I'm putting as a disclaimer that this project is not one supported by the echopen's association. Even if I'm a cofounder of echopen, this project is a personnal one, for the echopen community. Clarified with hackaday, not an issue for them wrt the prizes.

2016-08-29 Hey from Liberia

got contacted for a partnership to improve, build, and crowdsell a set of modules. Interesting!

2016-08-30 Some good news

Got some feedback of PRUDAQ's people on the doc, thanks to them for this contribution!
Zach's been back. Let's see what can be done.
Prof Charles is going to be in Paris: let's meet!
Been invited to speak at Hackaday's show for its prize on Nov 5th
Trying to get the latest HV7360 from MC.. seems difficult to say the least

2016-08-31 Habitat numerique

Thinking about the use of the "Logiciel and Objets libres, animer une communaute autour d'un projet ouvert"
Interesting : STBone - BeagleBone form-factor STM32F427 board
Doing some thinking about the servo part -- should be integrating a feather + screen to help debug the output =)

Resources:

Blogs

Support?

http://www.opensourceimaging.org/

Do you work on an open source project with potential application for MRI or other related medical research and technology? We will also highlight early stage projects (prior to a stable release and documentation) in order to improve collaboration at that early stage. Let us know and contact us at [email protected].

Would you like to support an existing project with your skills and expertise? Or do you have any more questions? Contact us at [email protected].

Forums a pinger pour un kit?

2016-09-01 A ping from GroupGets

It’s not a surprise that our backers waste no time getting inventive. We were pleasantly surprised by a tweet to check out this novel application of PRUDAQ in a DIY Ultrasound Imaging Platform. source.
Need to find a way to clarify a CLA if forking this repo to somewhere else

2016-09-02 JOH

Thinking of preparing an article for the JOH (or HardwareX ?)

2016-09-03 Cheers Sandeep!

An interesting VT100, USB-enabled - https://hackaday.io/project/13273-diy-vt100

2016-09-07 Back in Paris!

Best hardware I've seen so far : Arduboy. Both a controler, a platform to play with, an arduino, ...

2016-09-08 AG of the assocation

Congrats @BiVi for the position ;)

2016-09-09 Random stuff as usual

Arduboy ? Awesome!
A design for Sleepy is taking place.. wood rules =) Need a water tank though.
An awesome thing to automate physical interactions with a phone, using https://www.tindie.com/products/hugs/tapster/

2016-09-12 Thanks Adafruit

[Comm] : got cheers from Adafruit, check this link =)
Made some progress with a i2c 128x64 oled to debug the Feather ADC, using this elegant doc.
Getting up to 1Msps with the Feather.
@done: makedoc should include a link checker.. everything starting with ](https://github.com/kelu124/echomods/tree/master/ should be tested and checked if existing. That includes images.

2016-09-13 Stand alone echoes visualisation

Same, for today's date, at Feather.

2016-09-14 With a servo

That is done. Videos to come.
Missing: sending through UDP.

2016-09-16 Wifi

Connecting to wifi: done
Beers @Stalingrad, and chilling =)

2016-09-22 More speed for data acquisition and streaming

This is getting better. Read the log on this repo. Arduino IDE code is here.

2016-09-23 Getting some raw images

Still this pulser issue, but the signal is correctly stored. More to download here. Captured through UDP streaming.

2016-09-27 Processing the raw images

Created the scripts to batch scan-convert and animate the images. More to see/download here
Hopes to get the STM32 go faster =)
Adding the croaker work to the gitbook .. and cleaning some remaining broken links during doc generation.

2016-10-02 VIdeo for hackaday contest

Done in halong bay

2016-10-20 Meeting and such

Meeting at HD, milestone with Bitmakers
USB key that does Pulser, Acquisition : http://www.lecoeur-electronique.net/cariboost_files/us-key_r4_0.pdf

2016-10-21 Update of Tobo

The pulser module used a HV7360, which went from a LFGA to a CABGA. The gerbers were updated accordingly.

2016-10-22 End of week

Trouve au hasard : "One material with exceptional acoustic properties is TPX (polymethylpentene) [Westlake Plastics Company, Lenni, PA]. Pour une sonde à 35MHz, mais ca peut donner des pistes de suppliers. (Ref 10.1109/ULTSYM.2001.991996)
Article being written at https://gist.github.com/kelu124/af9e3b39b0ba8bed3bde250489635fa6
Onboarding Pouya =)

Next week:

@cancelled 6Msps on the STM32
@done Sourcing transducer (in cletus )
@done Sourcing materials + integration makefile par set
@done Compiler output

@perso : faire un eink tablet

2016-10-23 Geeking

Over engineering ? https://d262ilb51hltx0.cloudfront.net/max/800/1*xzS-UkYtNOgzPvpkHGwRbQ.png
Found an interesting octal transmit board : http://www.ti.com/tool/TX-SDK-V2
Update of the references list

2016-10-24 Geeking II

Skype with wayne.edu -- maybe modules ?
arduino legos : awesome form factor https://twitter.com/bwshockley/status/789971893356900352
Paris on t'aime http://www.konbini.com/fr/tendances-2/paris-mairie-video-anne-hidalgo/
http://www.npr.org/2016/10/21/498734538/black-mirror-is-back-reflecting-our-technological-fears
http://www.bandits-mages.com/rencontres2016/ressources/
Darkness https://www.poetryfoundation.org/poems-and-poets/poems/detail/43825

2016-10-25 Financing through ebooks

e-book generation at a. : https://medium.com/@aayushu/how-i-make-400-a-month-in-passive-income-by-self-publishing-68fa948edff5#.8h9udy2ad

2016-10-26 Playing with a photon

http://arduino.stackexchange.com/questions/12079/compatibility-between-particle-photon-and-arduino
http://arduino.stackexchange.com/questions/30551/using-arduino-ide-on-the-particle-photon
https://store.particle.io/ 19$ le photon
Chopper un ESP32 ?
Chopper un photon chez hackspark?
Follow up with Zach - modules?

2016-11-01 On Tindie

Check out https://www.tindie.com/products/kelu124/ultrasound-imaging-analog-processing-module/

2016-11-03 Having fun with batteries

https://hackaday.io/project/16358-pix-e-gif-camera

2016-11-05 State of the art

https://github.com/RemediOSM/UltraSound
https://github.com/sigurdstorve/OpenBCSim to generate US images

2016-11-15 Some lag, new job

Just started a new job 10 days back, so I lagged a bit. However, some news!

Sold two boards so far on tindie - which also gave opportunities to discuss with people: awesome.
Auto documentation moved forward! Plenty of new debug options in the doc generation journal
Some metadata on md files on board
Trying to get 2 probes on ebay for testing purposes
Some forum at
- https://forum.arduino.cc/index.php?topic=79285.new#new
- http://forum.arduino.cc/index.php?topic=177489.0
Posted something on reddit as well: https://www.reddit.com/r/UltraResearchers/comments/5dc13w/ultrasound_imaging_open_hardware_devkit/

2016-11-20 Week end

Shipped a first module!
Worked on a review of the autodoc generation script
Submission of a summary (or soon to be JOH article) to arXiv
Discussions with http://www.ibme.ox.ac.uk/research/non-invasive-therapy-drug-delivery/people/dphils/visa-suomi for interesting applications =)
Follow up with Fouad & Sven

2016-11-20 Terrible

Two awesome articles

Portable low cost ultrasound imaging system: M. Sobhani contacted =)
A low-cost high-fidelity ultrasound simulator with the inertial tracking of the probe pose

2016-12-01 arXiv

Published! [Article: A low-cost, arduino-like dev-kit for single-element ultrasound imaging)[https://arxiv.org/find/all/1/all:+AND+ultrasound+arduino/0/1/0/all/0/1]

2016-12-06 Press review

Working on a press review, can be seen here
@done: AddPressReview to the main page here, and on the gitbook
@done: review the latex article on arXiv, especially with respect to references
Need to ping Jerome for the BGA update of HV7360
@done too:
- Servo + Feather
- Servo + BBB + enveloppe
- Servo + ADC on board + RPi0
- Servo + BBB + raw signal
- BBB + probe
@done CERN !

2016-12-08 Connecting

Chatting with Gnusha

2016-12-11 Just moved in

Just moved in to the new flat! Exhausting =) Other interesting things:

https://hackaday.io/project/7225-low-cost-x-ray-systems-for-developing-nations

2016-12-17 Breadboard phantom

Done some tests with a breadboard phantom: read more here.
Still moving in the new flat, getting accustomed to the new job.. and still need to sort the hacking tools in a limited space in the new flat =)
Interesting competition : Clarius got its approval. Also noted the SONON 300C.
Having fun with mapping a community using slack. On another repo.
Published some update on the ML.

2016-12-19 Adding devices

See the list of similar handheld, low cost devices
Integration of previous steps in the gitbook

2016-12-26 Raw ideas

Max RPi speed : http://d-fence.sytes.net/raspberry-pis-gpio-speed/ @done --> do it with the Rpi0
- http://codeandlife.com/2015/03/25/raspberry-pi-2-vs-1-gpio-benchmark/
- Using the same experimental setup, the Raspberry Pi 2 is about 2 to three times faster. The fastest is still the C native library, topping out at just under 42 MHz.
Thinking of 20E-214 and moving to Alibaba for wireless probes. Will F.'s support reach?
Using Vitamins for the gyro's probe. What name still for it? Longinus?

2016-12-29 Moving forward

Getting to think of the 20E-214 ones =)
Chat with 1Tech, and the guy Patrice. Motivating.
Trying to get some stuff from the arduino, namely to get it work as a server. Far from being finished, on it.

2017-01-02 Merry new year

20E214
- Getting a propal from PR
- Fouad offering to test the 7.5MHz linear
- Me to check other suppliers
Some modules finaly added to the echopen's community medkit repo and added a config, the wireless 1.1 config.
Added a version of my jupyter notebook to explore the dataquarium data from the dataset released end of Dec '16.

2017-01-10 Heated debate on ultrasound prices

Some info on HN :
- a great discussion on hardware at https://news.ycombinator.com/item?id=13230741
- https://patents.google.com/patent/US4446395A
- a blog post by NF at http://liesandstartuppr.blogspot.fr/2016/12/why-are-medical-ultrasound-systems-so.html
https://github.com/MedtechDiagnostics/video2dcm
Bonus? http://liesandstartuppr.blogspot.fr/2016/12/quick-guide-to-spotting-non-existent.html

2017-01-10 Consolidating

“We do not grow absolutely, chronologically. We grow sometimes in one dimension, and not in another; unevenly. We grow partially. We are relative. We are mature in one realm, childish in another. The past, present, and future mingle and pull us backward, forward, or fix us in the present. We are made up of layers, cells, constellations.”

Presentation to ESPGG, participated to.
Hardware:
- went to solder some stuff at HD
- UltrasHound -- moving forward
- Beaglebone PRUDAQ image added.
Added some details (better raw image quality) to the SigProc 101 jupyter notebook.
Interesting paper on Theory of Change.
Peter confirms the probe is on its way.
JOH article: first comments received. Harsh, but good to move forward! And adding a couple of images, better introduction, ...

2017-02-11 Diverse

Moving things forward with the JOH article
Testing the RPi0 max GPIO speed to try it with the goblin ADC
Full day meeting for PRJ methodo.

2017-02-12 Diverse

Fun: http://hirelofty.com/blog/how-build-slack-bot-mimics-your-colleague/
Playing with markov chains : http://agiliq.com/blog/2009/06/generating-pseudo-random-text-with-markov-chains-u/

2017-02-19 Update to Doj and such

Thinking about an update for a neat, silkcreened, well designed motherboard. Would be excellent for Altay, Felix and maybe
Been doing some progress about the HV - working with Lorena to get one on board. I'll have 2 pulsers, will ask for 3. In total I'll still be able to send to (Afreen/Felix/Altay) + one for the GroupGet friends. Would leave me with one.
Afreen still working on the feather, after contacting the PRUDAQ guys.
Get Felix on Slack?
Call scheduled with Fouad on tuesday
Making progress on 20e214 - control of the probe OK. Display remaining, then CSV saving.
Taking more time about the Slack bot: lower priority
Update by Tobey: he found a way to compare PDFs.

2017-03-01 RPi0

See this log

2017-03-02 RPi0 bis

Given RPi0 capabilities in terms of GPIOs - why not push it to 20Msps, 8 bits, for the cape?

2017-03-05 Grmbl netty

Netty isn't nice... but just got my article accepted by JOH !

2017-03-06 Further work

Updated the suppliers repo
Testing the goblin In/out transfer function on the emulator signal: read here. The more I play with Jupyter notebooks, the more I like it.
Thinking about the 15 - 20 - 25 Msps pHAT.
Moving forward with the Netty issue at @20e214
Fun pHAT : IR : https://hackaday.io/project/20178-anavi-infrared-phat
Radio pHAT : https://hackaday.io/project/20199-empedocles
Interesting read: https://medium.com/@lhartikk/a-blockchain-in-200-lines-of-code-963cc1cc0e54#.kxsh35e7i

2017-03-12 DOIs for releases

While preparing the article, I've been invited to "save" of copy of the repo into Zenodo (see the backup. And I've got a nice Zenodo link!

Taking time on 20e214... still sucking at 20e214.
Waiting for the CA3306E to reach !

2017-03-19 Finish Doj

Working on Doj and releasing the KiCad definitive code - available on OSHPark.
PCB of the RPi0 high-speed ADC is ongoing !
Getting the last touches to the JOH article.

2017-03-20 Doj ... unfinished

Indeed. Forgot to add a ADC input directly from a strip, two strips for PulseOn and PulseOff, and a way to control the servo from the Pi.
Also starting the new season of the HackadayPrize =)
Still some issues with bomanz (on HAD) PCB. Some pads suck. I guess I'll order the board from OSHPark along with Doj's and solder all these tiny stuff. Not so many actually.

2017-03-21 Moving forward

Posted the Chinese probe project on Hackaday. Will play with the probe using a RPi framework. Should do the trick =)
Following up on 6Msps upgrade, mother board seem OK, silkscreen to do, then Pi1 and Pi2 to follow.
History to develop.

2017-03-22 JOH ongoing !

Got published! http://openhardware.metajnl.com/articles/10.5334/joh.2/
HAD some great projects: https://hackaday.io/tfogarty and https://hackaday.io/project/19685-early-and-low-cost-detection-of-heart-failure

2017-03-25 Studious week end

Some great discussion on use of doppler for heart issues, notes being here. Interesting DIY vintage doppler to do!
Put all the information on the Trove temporarly before uploading to the main repo.
Updated the Doj, Bomanz, and the CA3306E board. Ordered as well on OSHPark, finally!

2017-03-30 Peaceful for once

Maybe have a demo of the ATL3+modules to Loic this we
HV7360 new gen should be ok
someone more on the waitling list for the pulser
getting some likes on the https://hackaday.io/project/20533-hacking-a-chinese-wireless-ultrasound-probe
boards are on their ways..
so it's quiet !

2017-04-04 Chinese probe SDK

Moving forward! Capturing some images from the probe, trying videos

2017-04-06 Purple

Got some PCBs for Bomanz, for both high speed and CA3306E ADCs.
Got some PCB for Doj, and tested those!

2017-04-12 Mounted boards!

Playing with DICOMs on Kina, should be ported to all images. Example of code yields funny dicoms.
Here's what the ADCs boards look like.

2017-04-13 Error, that's hot

Tantalum capacitor: not in reverse! Never!! What are the odds that I put all 3 capacitors on 2 different boards all in reverse ?

2017-04-15 Capacitors connected

That's well and done. Shall be trying this week end!
Got 50$ bonus from OSHPark... yeay!!
Tweet proposed by "Cool, well if you want to release it as a product or anything then let us know and we'd be happy to help :-)" @PiSupply

2017-04-17 End of week end

Working on the press review
Backing HIDIOT : HIDIOT Kickstarter Edition Kit
Yeayy! Bomanz on OSHPark
Where to do next PCBs?
- http://www.pcbcart.com

2017-04-23 Playing with ADC

Playing with ADC.. got the first results with the CA3306E board! See https://github.com/kelu124/bomanz/blob/master/CA3306E/20170422-FirstAcqs.ipynb
Played with Loic on the RF modules
@cancelled dig into CMOS Ultrasound Transceiver Chip for High-Resolution Ultrasonic Imaging Systems.

2017-04-30 Playing with ADC - v2

https://github.com/kelu124/bomanz/blob/master/20170430-PushingADCLimits.md and at the bottom of it.. the next steps (for tomorrow? ;) )
from @rbo http://linuxgizmos.com/google-assistant-sdk-dev-preview-brings-voice-agent-to-the-raspberry-pi/
Bomanz on Hackaday http://hackaday.com/2017/04/30/hackaday-prize-entry-high-speed-sampling-for-the-raspberry-pi/

2017-05-05 Moving forward

Been testing new iteration of Tobo with new HV7360. Pulser works with the pulser control
Testing the pulser with the RPi Control.

2017-05-13 Some new stuff

PCBs for Doj V2 - see what it looks like are ordered
@done contact Sonopen / microsonix
Exploring Underwater Imaging Using a 1 × 16 CMUT Linear Array
@done add Felix, Will + Jp, Charles, Md+Afreen
@done add Visa, possibly Pouya and Thomas as contributors
@done map interested (green)
@done map users (blue)
@done add OSH license
@done start an order for pulsers
@done start a quickstart
2E: 54+148.96 = 202.96
Different systems
LT todos:
- Using an adapter for the motors control of the ATL probes
- Using a 3 to 8 CMUT with a multiplexer =)
- Adding a pulse control from the kernel module / driver for bomanz

2017-05-15 Interleaved on RPi.

Still about the RPi0 high-speed ADC : if I can't get above 10Msps due to a memory copy time, I may be able to double the speed by having 2 ADCs interleaved... it's to test!
Some answers for the CMUT stuff.. let's see if it's going somewhere !
ATL probes connectors are LEMO 18 or 19 pin.

2017-05-16 More todos.

Discussing with groupgets
Some guys forking the Kina repo =)

2017-05-19 Bomanz interleaved

PCBs sent for a High Speed ADC pHAT v3. This time, two interleaved AD9200s.

2017-05-20 Working on ATL3

Managed to get a peak into a ATL probe - update to the ATL probe.
Working on the offset

2017-05-22 Testing Doj v2

Got the PCBs and tested them. Yeayyy, they work! Slight hiccup with the ADC, nothing dramatic though =) Actually, two pins have a double use along with the ADC pins. Dumb me :p

2017-05-29 Testing Doj v2

Pushing some pics of the devkit 2.0 - note that this config allows pulse transmit. Pulse from the pulser, receiving through the analog front end.. and acquisition managed by the adc and raspberry.
Note to self: this config requires a "good" usb power supply. It succeded with a 5V 750mA power supply - but failed from USB.
@todo Add a documentation server
@todo Display IP on the OLED.

2017-06-09 Lots ongoing !

Got the boards for Bomanz v3 and SMD stuff
Sold some boards
@done Need to have a look at this RPI GPIO DMA - https://github.com/hzeller/rpi-gpio-dma-demo
@done Include some cletus remarks (sourcing) on gitbook
@cancelled convert all previous images to dicom
@done answer some questions online for RPI + ultrasound
@done add the at todos to the shopping list (see here ) by means of a grep -> temp file
@done Test YAML data on Markdown files (see contributors)

2017-06-11 Testing the ADC

Butchered the ADCs.. but I think I got the interleaved thing !
Adding officially the ADC pHAT to the modules as elmo =)
A summary of the Pi HAT test with the modules to image.
Debbugging the ADC inputs

2017-06-13 Getting into signal processing

Managed to get the offset by inserting a 100pF capa in series with input
Testing the ADC now with the Offset, see notebook
RPi Article to be started
http://gnusha.org/~gnusha/logs/html/2016-06-06.log.html as reminder of former tests

2017-06-19 Finishing the RPi Doc

Nothing much to do / say
Added a benchmark for components
Some ideas more to promote this product for A-mode tools
http://hackaday.com/2017/06/19/twenty-iot-builds-that-just-won-1000-in-the-hackaday-prize/ =)
http://www.ebay.com/itm/41139-5-7-5-MHZ-ENDOVAGINAL-ULTRASOUND-TRANSDUCER-PROBE-142252/391810622241?_trksid=p2047675.c100005.m1851&_trkparms=aid%3D222007%26algo%3DSIM.MBE%26ao%3D2%26asc%3D41376%26meid%3D7c8962ca8fe34037884411c7eaad4a6c%26pid%3D100005%26rk%3D2%26rkt%3D6%26sd%3D252386695621 : array ?
http://www.ebay.com/itm/ATL-MFI-7-5-5-0MHz-Cat-4000-0271-03-EndoRectal-Probe-3316-/111904974005?hash=item1a0e0e64b5:m:mkMb5fsyIlR5o1t1srcqOwA
Awesome capsule work: http://sci-hub.cc/10.1109/TMI.2017.2699973

2017-06-22 Consolidating ideas

Hussain: I have 5MHz PZT with 10mm diameter and 0.4mm thickness . I made the backing and matching layers, also I used fluorosilicone rubber for acoustic lens.

2017-06-26 More interest

put probe on the setup
@cancelled set the gain on the AFE using Doj v1.2
@cancelled use the GetSuppliersList function to list equipment suppliers
@done map the /include/community persons on a python map https://peak5390.wordpress.com/2012/12/08/matplotlib-basemap-tutorial-plotting-points-on-a-simple-map/
@done get stats from hackaday 1,2,GHMurgen,GHechomods,JOH

2017-07-01 More interest

@done Add contributor map to RPI doc
@done Add different images from acquisitions to RPI doc
@done Add the @kelu include("/include/AddUSSDK.md") function to makedoc --> use for the RPI doc (contributor, set costs, intro ... and readmore)
@done Complete the AddHistory with links for HAD
@done add benchmark to gitbook resources

2017-07-02 Testing the probe

Testing the counter for probe turns - see in the probe readme_.
Added the Pi article - support from Marc / Thomas ?

2017-07-05 China

Doing some analysis of the CN producers
@done Add PCBA
Back in touch with GroupGets
attiny84 (pinout): 12 pins:
- Config 1
  - 2 pins pour communiquer avec le RPi (maybe only 1) to address the multiplexer. Send 4bits pour multi 1, Send 4bits pour multi 2 = 1 byte. Reception: 1 byte retour + que des 1. Cf here
  - 4 pins pour 1 multiplexer -> leds
  - 4 pins pour l'autre multiplexer -> leds
  - 1 pin pour DAC
- Config 2
  - 2 pins pour communiquer
  - 4 pins pour les multiplexer
  - 2 pins pour les enablers
  - 1 pin for VGA :)
Maybe ATtiny2313 ?

2017-07-08 Doc 'n test

Received the cable for the probe
- @done fill in probe if necessary -> need oil in it (see AMZ)
- @done test probe with oil -> to redo
@done Test UHF probe
@done fill in /wordofcaution.md
@done integrate thomas remarks in RPi
@done update ppt_us with links all around
Templates
- [ ] AddPitch.md.tpl
- [x] @done Add TPL list
Nice patent : https://www.google.com/patents/US4246792
Updated the first draft of the alt.tbo

2017-07-09 ADC boosting

Awesome paper - how to boost the ADC - https://www.ncbi.nlm.nih.gov/pubmed/28368803
Testing a counter with the 32u4 -- see data
@done order tobo.alt
@done board pulser + processing + ADC for RPi
https://petapixel.com/2013/03/13/the-helsinki-bus-station-theory-finding-your-own-vision-in-photography/ : excellent article on finding your way.

2017-07-14 ADC boosting

New tester at http://www.usultratek.com/PDF/PicoPulser.pdf
Testing double ADCs interleaved
Cleaning the RPi: https://raspberrypi.stackexchange.com/questions/4745/how-to-uninstall-x-server-and-desktop-manager-when-running-as-headless-server

2017-07-15 Probe et al

Testing the probe + elmo setup: here

2017-07-18 Further tests with servo

Testing with the servo
Power in a piezo element
@done add some ideas for the pulser to the alt.pulser board
@done get orders from Sam CN.

2017-07-21 News from Newcastle

Interesting article on synthetic aperture - PDF
New article from Neasham - PDF -- some sources for good references
- Tech insights: using a 12Msps ADC for a 4MHz piezo and a 4 FPS - software limited, using a Voice Coil Motor (VCM -- see "Design and optimization of a voice coil motor with a rotary actuator for an ultrasound scanner," by same author ) for low noise, 15cm deep, 200 lines over 50°, 96V pulses, using synthetic aperture focusing on sig proc -- and they have already been doing in FDA compliant in vivo testing, Table III shows tech specs achieved.
- Also introduces some "low-cost devices recently entering the market include the Interson SeeMore probe, the SunBright SUN-806F and the Telemed MicrUs, which can be purchased between $1.5k and $3k.".
- Feasibility of Swept Synthetic Aperture Ultrasound Imaging - PDF
- Design and Optimisation of a Voice Coil Motor (VCM) with a Rotary Actuator for an Ultrasound Scanner - PDF

TODOs:

@done remove gitbook MD files from the log
@done link to files in the log (python)
@done put back good ino for pulser
@done quickstart installs and tests (see Charles email)
@done finish the Word of Caution MD

2017-07-24 Where is IvanTch

Trying to find him https://github.com/Ivan-Tch/OpenUltrasound =)
https://docs.google.com/document/d/1xvLWDbp0x6z0Ft3AsfxjIsLUNsg5smkTcYb1g4WVo5U/edit
Mechanical sweeping probe image from http://www.mdpi.com/1424-8220/14/11/20825/htm

2017-07-26 GitHub searches

hv7360 -user:kelu124 -org:ech open -org:echopenHQ
ad9273 -user:kelu124 -org:echopen -org:echopenHQ check for FPGA for probe..

2017-07-28 Thinking of an end

Got some amazing responses to the post on HN, held the 1st pos for an hour +, got over 200 ups, that's quite enough =) I guess I'm coming close to an end on this project, and my target would be to try and have a presentable project before Year 2. The five key milestones:

Outreach: I have sold 10 kits so far, have ordered 5 sets more to a CN PCBA. Will sell those - and let people choose what they want when they'll want to play with those. I guess I'll have the community Milestone reached when someone provide a significant improvement / publishes thanks to this kit. Status: 50%. Bonus point if a unreached continent so far is involved.
- ENDOFYEAR: 15 kits sold, CN not good, MF ongoing (20171217)
Money: thanks to the small margin on kits, and hackaday prizes, i'm quite cash neutral as of today. Having the 5 kits sold would permit financing the acquisition of the unmantled CN probe. Status: 100% Bonus: trade the chinese probe on leboncoin / ebay. Status: 0%
- ENDOFYEAR: still waiting (20171217)
Product: I wanted to have a ultrasound hat done. I now have this ADC pHAT done, which can be perfected, but it's quite a win, so a simple 80V monopolar ultrasound board (independant from the motor / multiplexer) could be reached by Nov. Status: 0% Update: could be good to use the probe head to do a full portable probe =)
- ENDOFYEAR: Ongoing with Matty (20171217)
Documentation: There are a couple of notes here, I'd love to see all of those gathered / processed / put into a braindump. Gitbook is good enough, but lack structure for raw knowledge dump. TODOS include:
- Listing all docs under YYYYMMDD
- ENDOFYEAR: Quite happy, having added experiments (20171217)
Future I'd be keen on having a 8 to 16 elements module prepared, just so to prepare the next gen and passing over of the project. Jan and Ivan to support. Status: 0% Muxing using ATTINY85 ?
- ENDOFYEAR: Shifting to chaotic masks ;) (20171217)

Nice to have:

A slack bot? It would be fun to have a supporting bot to answer queries, like "where are the elements benchmarked, how do you process dicom, ..."

2017-08-05 Moving forward towards the board

Added something about the S3 probe
@done Adding the descs for modules and power needs
@done Removing double Autogen tags
@done Main readme as TPL
@cancelled DICOM rest of images
@todo test some compressed sensing using golay codes on a single element piezo

2017-08-14 Zach

Zach's work has been published on https://www.youngscientistjournal.org/article/development-of-a-portable-and-inexpensive-ultrasound-imaging-device-for-use-in-the-developing-world =)
Got the probe -- need to open it and explore it =) (or here in local).

2017-08-17 Some RPi code

Working to get a transducer schema?

http://www.brl.uiuc.edu/Downloads/bigelow/APPENDIX%20C.PDF
http://www.biosono.com/PrmtLgd/PrmtLgd.php?id=TrnsRlc
Add http://datasheet.octopart.com/MD1210DB1-Supertex-datasheet-164548.pdf in bench - theres a RC circuit to simulate a transducer
Check python scripts from Mark

Documenting pictures:

https://stackoverflow.com/questions/936937/which-exif-tag-to-store-keyword-tag-for-a-photo - LocalCaption
https://photo.stackexchange.com/questions/52515/whats-a-good-exif-metadata-field-to-store-a-general-url-about-photo-topic-conte -- Caption-Abstract/Description // Headline
https://sno.phy.queensu.ca/~phil/exiftool/TagNames/EXIF.html -- ImageDescription

2017-08-21 Remaining time

Got 3 months left (see 28/7), let's do... a MASTER TODO !

Test board
- Get DSO by 10/9
- Get signals by 30/9
- See ICs and get a summary by end of oct.
CNFab
- Get maps
- Send maps
- Receive alt.tbo and lite.gobs by 15/9
- Test those
- Put them on tindie with ADC pHATs
Gob
- Start order with EF
- Benchmark UF
atl.tobo.cheap
- 31/8: Start design
- 10/9: Get it to MF
- 10/10: get it and Test before 20/10
Single board
- Get alt.tbo.cheap tested
- Start design by 10/10
- Get sent to macrofab by 25/10
- Receive board by 25/11

More Raspberry Pi Zero notes

2017-08-24 Some more ideas

Getting a 18650 battery (x2)
Getting battery board (x2) - board and tofs -- see https://hackspark.fr/fr/electronique/puissance-et-energie/stockage-batteries.html & battery holders
Touch sensors
https://hackspark.fr/fr/12mm-domed-push-button-pack.html // https://hackspark.fr/fr/joystick-breakout-module.html // https://hackspark.fr/fr/mini-sliding-switch-dpdt-6-terminals-0-3a-6vdc-2-positions-2mm.html

2017-08-28 Not much time

not much time, but let's see. The board design is making progress.
- Basically, need to review the pinout for the RPi Header
Got the DSO, will do some tests
Will start investigating a minima with the tobo.alt design
Image tagging with http://tilloy.net/dev/pyexiv2/tutorial.html

2017-09-02 Making the images better

Adding metadata to the images
explore:
- ImageDescription

2017-09-09 Playing with the probe

Been starting the probe teardown page
- Checking the pulses
- Motor control?
Finetuning the img metadata
Need to plan for the oneboard design

2017-09-15 Slow progress

Need to make some progress on Uniboard
Some feedback from Marc, and Felix supposed to come to Paris !
Trying to master the probe counter
Need to have a script to edit Images tag
Fab is making progress on tobo.alt and goblins, gobs form EF coming too!
Challenge issued to boost GPIO read speed. 12Msps so far on the RPi0 so far ... x2 with the ADC cape, how fast can it reach?

2017-09-17 Progressing on autodoc

Adding experiments to the docs
@done adding the experiments for within the MD files
@done create files for experiments in include (eg in /include/experiments/ ) (using ListOfExperiment )
Opened a bit more of the S3 probe
Ordered some JST for the probe

2017-09-29 Moving forward with tests

@fail test s3 outputs w/ JST - and good trigs on DSO203
@done feed s3 in 5V in motor w/ JST -> fail
@done Test Gob
- Relancer le fab_cn ... error in its capa placement
done: test ADCs
done: test Pulser

2017-09-30 Some experiment

Done the tests for the pulser ( 20170930a )
Some additional works for the motor control
@cld a better bilevel control (4 NOPs period -> PPon, Poff, PNon, PNoff)
@cld float pins between shots? -> work session on bilevel.c
@cld pass license to CC-BY-SA
@done add some new articles to the new article (all put to bibtex)
- Some interesting read .. again: 10.1109/ULTSYM.2013.0142 for bimorphs
- Article: A flexible multichannel FPGA and PC-Based ultrasound system for medical imaging research: initial phantom experiments for brazilan students working on a design
- Article: PC-BASED ULTRASOUND IMAGING SYSTEM IN A PROBE
- https://www.intechopen.com/books/ultrasound-imaging/hardware-software-partitioning-of-digital-signal-processing-in-ultrasound-medical-devices-a-case-stu
- Article: Development of a Low-Cost Medical Ultrasound Scanner Using a Monostatic Synthetic Aperture
- Article: Effect of frequency characteristic of excitation pulse on lateral spatial resolution in coded ultrasound imaging
Demo mode for clarius : https://www.clarius.me/quickstart/demo-mode/

2017-10-06 Articles on the way

UniBoard making progress :)
Some new articles:
- Article: A Deep Learning Approach to Ultrasound Image Recovery #CompressedSensing :)
- Article: Ultrasound Image Quality Assessment -- A framework for evaluation of clinical image quality
- NiftyNet: a deep-learning platform for medical imaging at https://arxiv.org/pdf/1709.03485.pdf

2017-10-21 Holidays soon off

Loving PoC || GTFO : https://www.alchemistowl.org/pocorgtfo/
Check : Lattice iCE40UL1K-SWG16 -- http://www.latticesemi.com/Products/FPGAandCPLD/iCE40.aspx (used on https://hackaday.io/project/6592-dipsy ) -- quite a small FPGA !!
Onboard gyro https://playground.arduino.cc/Main/MPU-6050 ?
@todo senjak 15:07 In Which a PDF is a Git Repository Containing its own Latex Source and a Copy of Itself -- https://github.com/ESultanik/PDFGitPolyglot/blob/master/make_polyglot.sh
FUp:
- SENT - https://www.ebay.com/itm/ATL-Access-A-Ultrasound-Probe-LOT-2-/131588905820?hash=item1ea34f5b5c:g:COUAAOSwyQtV3Xkg&autorefresh=true
- TOBESENT - https://www.ebay.com/itm/ATL-5-0MHz-Access-A-12-7mm-Dia-6cm-FP-Ultrasound-Probe-3238-/291684630810?epid=1258231447&hash=item43e9c2411a:m:mmiDQT-0egKab5ctOAd5igw
eBay
- Kretztechnik
- https://www.ebay.com/itm/KRETZ-Transducer-NW15C-Sektor-Combison-Ultraschall-Sonde-ultrasound-/152724129257?hash=item238f1145e9:g:3ZIAAOSwB-1Y2YEq
- IRW77AK
- S-VRW7-10
- WAW4/5B -- http://www.ebay.at/itm/KRETZ-WAW4-5b-Sektor-Combison-301-311-310-320-Ultraschall-Sonde-ultrasound-/152724129249?hash=item238f1145e1:g:hVsAAOSwsW9Y2YCF
- ALOKA : https://www.ebay.com/itm/ALOKA-3-5-MHz-Sector-Transducer-for-SSD-118-240-260-280-633-650-725-/253136353004?hash=item3af01a36ec:g:z~4AAOSwARZXmoUP -- ALOKA SECTOR
- S-VRW77AK -- small piezos
- Emisonic 4264
Businesses
- UpAccelerate mscan. Mobile ultrasound device. price 600$. It is a business, but one to benefit maternal health https://t.co/aeogOzmZH3 -- looks like http://mscanug.com/wp-content/uploads/2015/02/pic-5.png
- https://www.geekwire.com/2017/echonous-announces-35-million-new-funding-mini-ai-driven-ultrasound-devices/

2017-10-23 Back to work again

@canceled senjak CAP1188 for touch ?
LightProbe: A 64-channel programmable ultrasound transducer head with an integrated front-end and a 26.4 Gb/s optical link 10.1109/ISCAS.2017.8050300
https://doi.org/10.1166/jmihi.2017.2220 FPGA Implementation of Speckle Noise Removal in Real Time Medical Images

2017-10-27 Back to FPGAs this time

https://www.reddit.com/r/cscareerquestions/comments/78rhz7/this_startup_asked_me_to_do_a_project_for_an/ I loled

2017-10-28 News from ther modules and pulser

DataScience https://jakevdp.github.io/PythonDataScienceHandbook/
Butterfly http://m.marketwired.com/press-release/first-ultrasound-on-a-chip-receives-broadest-fda-510k-clearance-2238621.htm 2k$
http://baruch.siach.name/blog/posts/linux_kernel_module_parameters/ (t1, t2, t3, t4) Pon, Pdamp, Pon, pdamp
http://www.tldp.org/LDP/lkmpg/2.4/html/x354.htm !! excellent
https://www.linux.com/learn/kernel-newbie-corner-everything-you-wanted-know-about-module-parameters
Commands
- modprobe foo parameter=value
- modinfo ambassador for params

Sometimes a kernel modules allows setting a parameter at run time. In this case you'll find the parameter under /sys/module/modulename/parameters/, with writable file permissions. The debug parameter of the ambassador module is an example of such a parameter. Set a value to this parameter with a simple echo command:

echo -n 1 > /sys/module/ambassador/parameters/debug

2017-10-29 What next now

Great topic: good feedback from users!

Another topic, got 1 month left before 25/10 (2 full years!), let's update the MASTER TODO !

CNFab
- Get updated goblins
- Put them on tindie with ADC pHATs
atl.tobo.cheap
- Review reason for pulser issues -- possible D2 issue
- Start macrofab bis.tbo after feedback on D2
ADC board (cancelled as of 20180401 - gone directly to final board)
- Trying a 50Msps board.
- Design start on Nov 1st
- Order by Nov 20th
- Receive by December
- Final tests in Jan
Single board (final)
- Design start on Nov 1st
- Design produced by
- Order by Nov 20th
- Receive board by December
- Test by Jan

2017-11-02 Nice application

2017-11-04 Checking shopping

Interesting exchanges on slack about glycogen measurements in muscles.
Ebay:
- Kretz Ultrasound Transducer https://www.ebay.com/itm/Kretz-Ultrasound-Transducer-Ultrasound-Probe-with-Warranty/232535663954?hash=item362434a552:g:ypwAAOSwgmJXyGus -- KRETZ AW145B -- NB on 5th: got it!
- ALT ADR on https://www.ebay.com/itm/Atl-adr-Ultrasound-Probe/253208770177?hash=item3af46b3681:g:798AAOSw7U5Y-QV3
- https://www.ebay.com/itm/ATL-ADR-5-5-MHz-7-mm-Ultrasound-Transducer-Probe-for-UM-4-7081/291683083141?hash=item43e9aaa385:g:9R4AAOSw1S9Wf4J4 https://www.ebay.com/itm/Used-ATL-ADR-Ultrasound-Probe-5-5MZh-7mm/253208621125?hash=item3af468f045:g:NcUAAOSwHHFY-QbI
- or others
  - https://www.ebay.com/itm/ATL-ADR-7-5-MHz-15-mm-Annular-Array-Ultrasound-Probe-Transducer-7078/291683083737?hash=item43e9aaa5d9:g:5BkAAOSw~otWf3fR
- Kretz 7.5MHzcal Transducer [wnw7.5av] Secteur combison
UniBoard : No external ram is fast enough with ICE40. Capitalizing on UP5K 1Mb RAM.
- 48MHz: couple of lines, full speed
- 128 lines for 130us, 8 bit at 24MHz, 6MHz BP out of 24MHz sampling
eBay search ultrasound probe -beauty -fetal -facial -gel -parking -sheathes -covers -dermabrasion -massager

2017-11-09 a bit of thoughts on fpga

UP5K does not have icestorm compatibility
HX8K is BGA
Remains is HX4K ... and needs additional RAM.
Nice project: https://shop.trenz-electronic.de/en/TE0876-01-IceZero-with-Lattice-ICE40HX
- https://folknologylabs.wordpress.com/page/2/
- https://folknologylabs.wordpress.com/2016/08/03/storm-in-a-pint-pot/
- This SRAM can be upgraded to 512K x 16
RPi FPGA/ https://shop.trenz-electronic.de/en/TE0726-03-07S-1C-ZynqBerry-Raspberry-Pi-Form-Faktor-with-Xilinx-Z-7007S-Single-core-512-MB-DDR3L?c=350
@done solder rest of Pulser
test the two probes I got

2017-11-11 fpga need to move now

FPGA

Open-source: ICE40 & RPi
Perfs: SRAM + HX4K at least: IceZero ? Take the design, throw in 8Mb instead of 4Mb
- IceZero board design can be reused
Silkscreening:
- Keeping a clear markup of the different functions
ADC: 10 bit, 65Msps
- 10 bits measures (or pseudo-12 with decimation ? by x3)
- 6 bits remaining by acq: 2 top tour, Pon, Poff, 2 IOs
Interact
- 2 buttons
  - Manual Trig
  - Select mode
- 4 LEDs
  - Single mode
  - Loop mode
  - Acq (ready: on, data in: flashing)
Modes:
- Single capture
  - 200us long captures at 65Msps : 208kbits
  - Capacity of close to 35+ captures if needed in RAM
- Loop
  - 130us acq at 24 Msps over 16 bits: 57.6 kbits
  - That's more than 130 lines over a 8000000 bit SRAM
Transfer back to RPi through SPI
Variables (to be stored as a header of the file sent back)
- Pon length
- Poff length
- Tdelay length
- Tacq
- RT -- repetition time
- N acq -- number of acquisition
- Implicit:
  - ADC bits used
  - Mode (loop or single)
Expose:
- i2c: min. a OLED screen space kept on board
- Gain Output
- Logic (bidirectionally buffered): Trig, Pon, Poff, 2 top tours, 2 extra IOs
- mini USB for power on
- 5V and GND pads

ebay

is Kretz VSW3-5 linear ?
same for SW4/5B ?
S-VDW5-8B for parts ? endoprobe

2017-11-12 fpga go

Call for clarification
Open toolchain is Verilog / VHDL / Lattice tools
130 lines of 150us at 24Msps on 16 bits is 7488000 bits
Worked on two experiments: pulser tests and testing new probe, and again, once the probe is refilled
@done 20171111a and 20171112b Readmes

2017-11-18 more veille on fpga

Ultrasound Imaging System for Educational Purposes --- excellent idea
Time Gain Control (Compensation) in Ultrasound Applications
Design and Construction of an ultrasound transmit pulser system for non-destructive testing
R&D at http://www.tonsonlabs.com/technologies/
Implementation of a Wearable Ultrasound Device for the Overnight Monitoring of Tongue Base Deformation during Obstructive Sleep Apnea Events
http://www.greenteapress.com/thinkbayes/html/thinkbayes001.html for stats
@done impedance matching -- see more -- Butterworth-Van-Dyke or here. Tuning Filter.

2017-11-20 Some electronics pulser and IMN

Pulser: http://www.google.ch/patents/US3989963
Excellents images : https://books.google.fr/books?id=7HQyBwAAQBAJ&pg=PT19&lpg=PT19&dq=by+manual+scanning+was+the+daily+routine,+a+member+of+the+%22salami+club&source=bl&ots=KU4G_lVoaL&sig=P-R_jzRnU1QUotDTlL005dr9ZEQ&hl=fr&sa=X&ved=0ahUKEwi9047M3c3XAhUOmbQKHb4eAXgQ6AEIKjAA#v=onepage&q=by%20manual%20scanning%20was%20the%20daily%20routine%2C%20a%20member%20of%20the%20%22salami%20club&f=false ( see 1.16.c for kretz images)
Impendance : see more -- the folder
imp -> power delivery x9 : Fig5 of https://ac.els-cdn.com/S1875389210001331/1-s2.0-S1875389210001331-main.pdf?_tid=c7792854-ce1c-11e7-8a8c-00000aacb361&acdnat=1511201046_10271c5cae5aabd00a8d4e68d491fc1a
- 560 pF and Lm=56uH
- 445-9145-1-ND for 150pF at 200V
Random: http://www.robertgaskins.com/powerpoint-history/sweating-bullets/gaskins-sweating-bullets-webpdf-isbn-9780985142414.pdf

2017-11-24 IMN at home

Testing some electrical impedance matching here
Cloud9 on a RPi:
- https://habilisbest.com/installing-cloud-9-on-your-raspberry-pi
- https://www.siaris.net/post/cloud9/
@done list other initiatives
http://imprint-india.org/a-low-cost-portable-super-resolution-ultrasound-scanner
http://ieeexplore.ieee.org/document/7950710/

2017-11-28 Matty-Senjak board

Two-year anniversary - FPGA yeay !*

Done on experiments!

2017-12-01 New stuff

After realizing at BiVi that US-SPI is simple... try new HV sources?

2017-12-03 Ongoing up

Working on a modif on alt.tbo to produce alt.tbo2 (VL)
Create a HV module (VL) from MAX5025
@done Having Gob on MF as well?
- WB1-6TSL to replace transformer
Nice black boards btw -- love the style
Download Matty2 (DP) from UV
- Push on MF. Tested price: 260$ for all.
Limits -- http://www.smbc-comics.com/comics/1510428871-20171111%20(1).png
https://hackaday.com/2017/11/28/hjwydk-the-journal-our-community-has-been-awaiting/

2017-12-05 News on MacroFab

Pushing Elmo v2 - with new silkscreen, Max5025,

2017-12-07 Updates again

Onboard DDS for impedance calcul ? http://www.analog.com/en/products/rf-microwave/direct-digital-synthesis/ad9830.html#product-overview
MAX5025 and Alt.tbo v2 - on MF
@done Elmo v2 / Gob (alt) ongoing work (ODB and transfo issues respectively)

2017-12-09 Illusion in a logo

@done Alt.tbo2 up on MF
@done senjak Matty ordered
@done Gob, Elmov2 at Vlad
http://blogs.discovermagazine.com/neuroskeptic/2017/12/08/curvature-blindness-illusion/ -- some waves for a logo =)
https://www.gamasutra.com/blogs/DoctorLudos/20171207/311143/Making_a_Game_Boy_game_in_2017_A_quotSheep_It_Upquot_PostMortem_part_12.php genial !
https://www.crowdsupply.com/andy-haas/haasoscope
http://gnarlygrey.atspace.cc/development-platform.html#upduino for FPGA and arduinos =) qui tourne sur un ICE40UP5K/3K-SG48 -- http://gnarlygrey.atspace.cc/downloads/UPDuino%20Programming%20with%20RPi%2020170626.pdf

2017-12-11 Is maturity here

2017-12-16 Chaotic good

http://physicsworld.com/cws/article/news/2017/dec/14/ultrasound-imaging-from-a-single-large-sensor by Kruizanga
Article: Ultrasound Imaging From A Single Large Sensor for the original article - or with a local article
MacroFab costs/prices model is reviewed
http://shyrobotics.com/2017/12/13/skywalker-prothese-de-main-controlee-ultrasons/ to be used with single large sensors for flat imaging!
Article: 8051 microcontroller to FPGA and ADC interface design for high speed parallel processing systems – Application in ultrasound scanners
@todo classifier articles with link Article: =)
@ushound https://wiki.analog.com/resources/tools-software/linux-drivers/iio-adc/ad7766 for ADC, SPU0410LR5H for mems
- 4 LED (listening, saving, ... ?)
- 2 buttons (save)
- SPI : DAC and ADC: 2 LEDS for the CS
@ushound: social activism around getting to know our ultrasound environment pollution
ADMP441 for I2S MEMS?
SPH0645LM4H-B est i2s
the AMP may be https://www.hackster.io/fvdbosch/raspberry-pi-zero-airplay-speaker-d99feb -- schematics are here https://github.com/adafruit/Adafruit-PAM8302-Mono-Amplifier-PCB and datasheet https://cdn-shop.adafruit.com/datasheets/PAM8302A.pdf
http://www.jinci.cn/en/showgoods/866.html
@senjak https://wiki.lspace.org/mediawiki/Latatian_Phrases ( Vilis Ad Bis Pretii // Si Non Confectus, Non Reficiat // Stercus, Stercus, Stercus, Morituri Sum )
- Nunc Ille Est Magicus ?
- Non Ante Septem Dies Proxima, Squiri
- Vilis Ad Bis Pretii

2017-12-17 Kipple

The things we carry // kipple // OSH
@ushound started again
app-wise, @ushound -> mailed sergio
http://www.smbc-comics.com/comics/1513526046-20171217.png

2017-12-27 eink and such

eink + esp8266 - https://blog.squix.org/wp-content/uploads/2017/10/ESPaper-Setup-Guide.pdf
macrofab ongoing
https://gist.github.com/pklaus/5921022 #arduino going at 1 #msps over USB !

2018-01-14 Happy new year

And stuff! Some good todos for this year:

@done added experiment from Felix
@ongoing better experiments scanning
@done readding description into experiment files
@todo a page sumarizing the experiments (as in the Experiments page in the gitbook)

Also working on a compilation of best open source projects using ultrasounds -- https://github.com/kelu124/openultrasoundprojects or https://kelu124.github.io/openultrasoundprojects/

Add some fun playing with ultrasound in public spaces

Also expecting delivery of a matty-senjak board soon =) Will defintely need to find a name

2018-01-15 Senjak and stuff

Still getting trouble getting a good name for Senjak, Matty... UnAurIce ? for 1Auris + ice 40 ? Anyhow...

IceCube2: need first to create an account
- http://hardtechlife.com/installing-lattice-diamond-on-ubuntu-14-04/
- https://hackaday.io/project/6592-dipsy/log/24272-installing-icecube-2-on-ubuntu-14042-lts
- http://soerenbnoergaard.dk/project_ice40_archlinux.html
  - pip install apio
  - Install the icestorm tools with:
  - apio install system scons icestorm
  - sudo apt-get install fpga-icestorm yosys arachne-pnr fpga-icestorm-chipdb
- Official packages:
  - http://www.latticesemi.com/Products/DesignSoftwareAndIP/ProgrammingAndConfigurationSw/Programmer.aspx
Other: working on a bibtex repo
Found out Columbia Open Ultrasound : just genius. Interesting AFE at https://github.com/ColumbiaOpenSourceUltrasound/Analog_Frontend .
@done Brainstorm for @senjak information design:
- Main branch (on GH) - sync'ed from matty folder
  - Presentation (on dmn.org as a static page)
  - Sources
    - Upverter
    - FPGA
    - RPi
  - Experiment examples
    - Simple Mode-A acquisition
  - Article GTFO
  - Article HardwareX / arXiv
  - - All In One PDF ? =)
- doc branch (on doc.dmn.org) -- sync'ed from matty/doc as a gitbook
  - Gitbook
  - Pages created from Experiments
- DATA files synced (not GH, on data.dmn.org) -- synced from matty/data

2018-01-28 Updating Senjak

Fun with TTGO - interesting full setup with https://fr.aliexpress.com/item/TTGO-TS-v1-0-v1-2-esp32-1-44-1-8-TFT-MicroSD-fente-pour-carte/32847643640.html
Removed MattySenjak clock, expecting new
Bought some ESP32 to play with
Preparing OSHW ?

2018-02-01 Un0rick clock oki

Clock is soldered again!

2018-02-02 Flashing Un0rick oki

Done! With the code, it works. I just need to rmmod ftdi_sio and usbserial =)

2018-02-03 Un0rick and RPi

Still some issues having SPI work.. let's try through RPi. Been adding the the jupyter to the board.
Why not have the CS0 on IO4, taht's

2018-02-13 Un0rick moving good

work making progress -- DAC working for the gain, Pon and Poff work, setting up the registers work..
Need to get something else than 0xAA on reading though =)
un0rick.cc booked -- will be home page / gh-page.
@done un0rick site to have plenty of stuff
- shop for stuff (or paypal ?)
- doc for documentation (from a gitbook)
  - Generated from echomods
  - includes list of datasets
  - includes article
- data for datasets
- git links to github
  - gh-page is homepage
    - Just a landing page
  - main is code for fpga / rpi
  - to contain article
  - to contain key doc (generated from echomods?) which will generate gitbook (or contains)
  - all of this in a self contained PDF containing
    - pitch
    - scientific article
    - poc-style
    - some goodies
BTW, un0rick light could be good! (UP5K, HV7361+MD0100!, no RAM, just pulser, few buttons, ... :) ) -- to be discussed / price checked.

2018-02-18 un0rick deadend

https://kelu124.gitbooks.io/echomods/content/Chapter3/matty.html Nothing works yet on the MOSI line... strange to read those. Version from 11/02 works still. To be explored!

On the good side, I had time to test the new Elmo v2 and Alt.tbo v2 boards:
- Comparing new and old pulsers
- With a new driver for the pulser and ADC

2018-02-25 un0rick moving again good

Getting first images ! Yeayyy =)
So now, getting to:
- @done Create matty module
- @done Publish first drafts on un0rick GH / GH-pages / gitbook
- @done create un0rick page on echomods gitbook
@done create v2 release once gob.v2 and corrected/working alt.tbo v2 are ready.
- done testing elmo v2

2018-02-27 progress on the ice40 board

HV Pulsers work! -- nice damping.
I got nice echoes day before yesterday (oops I mentioned those already)
Got images with a probe yesterday
@todo use General Design Procedure for Free and Open-Source Hardware for Scientific Equipment as a reference
nice 5V to 170V booster with the schematics.
Get inspiration from this inspiration

2018-02-28 Documentation and comparisons

@done compare old pulser for matty readme
@done automating finding readmes of experiments

2018-03-05 Going to rick

Iterations for next steps:
- Roadmap for the next evolution
- Phantom in PU to do ? What accoustic impedance?
- @todo for matty Rip this intro?
Other stuff: explore ETH
@done clean all repos for a v2 release of modules
- Elmo : OK!
- Alt.tbo
- Gob

2018-03-06 Going to Rick

Launching matty v2 -- prod version
Publishing it on un0rick.cc
Explore USED Bard Site Rite - https://www.youtube.com/watch?v=8iUkeJvSXtE (v3) or https://www.youtube.com/watch?v=qxanLwW8EL8 (v2)
- Bard Site Rite 37522 5C-45C 7.5MHz Ultrasound Transducer Probe 68mmFL Dymax 0470
- http://journal.chestnet.org/article/S0012-3692(15)46601-2/fulltext
- @todo decrypt the connector for the Bard probe

2018-03-08 Cleaning repos

Release v1.9: echOmods : legacy release
- clean broken links
Release v2!
- @done Script to check IMGs URL matches path
- @done reorganise
  - keep v2s of elmo, gob, elmo, alt.tbo
  - remove others in
  - gitbook -> Have a "Legacy" chapter
  - Quickstart : replace pulser by alt.tbo
  - Readme actuel becomes Readme_legacy.md
- Experiment summary
  - List all experiments in Summary
  - Create summary page
- Create Full Biblio.md
un0rick.cc up and running! Gitbook as well as data, doc branches are up too.
OSHWA too !

2018-03-10 Documentation to come

Matty v0.1 preprod files pushed
Matty DAC tests seem OK
Create un0rick.cc doc .. seems doxygen supports both VHDL and python, perfect!
- https://www.stack.nl/~dimitri/doxygen/manual/docblocks.html

2018-03-14 Phantom ideas to get

Polyurethane-Casting-Resin.html http://www.easycomposites.co.uk/#!/resin-gel-silicone-adhesive/casting-resin/Xencast-PX90-Semi-Flexible-
Speed of sound in rubber-based materials for ultrasonic phantoms https://www.ncbi.nlm.nih.gov/pmc/articles/PMC5126009/

polymeric materials include neoprene, ethylene propylene diene monomer (EPDM) and polyurethane rubbers

http://www.easycomposites.co.uk/#!/resin-gel-silicone-adhesive/casting-resin/Xencast-PX30-Soft-Flexible-Polyurethane-Rubber.html
http://www.ondacorp.com/images/Rubbers.pdf
http://www.acousticpolymers.co.uk/pages/profile.html
https://www.ncbi.nlm.nih.gov/pmc/articles/PMC3651250/ or 10.1118/1.4802083
Loved Nasa: @todo add to un0rick

fow uopeytdeus hesor tpe wonfretuw ca amwi et detr ip fos zopwyaiod conwe ah wousgt Tepan afew conseion et mew

ice40 again at https://www.element14.com/community/thread/43876/l/project-icestorm-fully-open-source-fpga-tools-for-lattice-ice40?displayFullThread=true

2018-03-16 Bard probe 1

Worked on a bard probe with matty
An interesting patent is here -- found working on the patent parsin' graph tool
- The more I glance at it, the more fascinated I become...
- There is no motor! Just electromagnets =)
  - Then no need for a stepper motor
  - it may be the case that
- The signal coming back is an already processed signal!
  - It means the pulse should come from another part of the board... ie another pair of cables.
    - Black and white? -> 5 ohm between this pair.. why not?
  - What about the other logics?
Next steps: trying and get the reference manual
Get full echographs boxes on ebay =)
- Plug plugs on headers while running

2018-03-20 Updates

Getting a Bard Site Rite III in the mail soon ? ;)
Probable supplier for mechanical probe in the pipe too !

2018-03-21 FPGA tools

Beginning with FPGA : https://www.mattvenn.net/2017/11/05/beginning-fpga/
yosys can use Graphviz to create interactive drawings of its synthesis : http://www.clifford.at/yosys/files/yosys_appnote_011_design_investigation.pdf
https://knielsen.github.io/ice40_viewer/ice40_viewer.html

2018-04-01 back from marrakech

Back from holidays!
Making progress on small probe
@done change path of images when they have changed
un0rick / matty v0.1 release! https://github.com/kelu124/un0rick/releases/tag/v0.1
@cancelled Create detailed pages for the community in the gitbook
@done Create detailed pages for each probe I've played with in the gitbook
Working on the bibliography and reput it in the gitbook
@done cleaning gitbook and pushing annexes

2018-04-07 Other dentist thoughts

@done add dp location
@done listing experiments of others
getting things straight with MacroFab

2018-04-08 Documentation process

TODO reclean full repo one gob2 and lit.tbo are tested

@done before reclean full repo, create release "Full Dev Resources" and get corresponding version (v1.9 + hash)!
- @cancelled : Add Full GitBook PDF to it before
@done Sort the list of experiments, shortnames in SUMMARY
@todo Community: list the contributors in a page + add the experiment. Individual page to point to experiment.
@done Page on documentation
@done Edit history page to add Matty.
@todo Rewrite the Chapters Readme -> "This chapter is dedicated to the brain_dumps "
@done Do a Doj (LOW PRIORITY)
@done Redo a usable alt.tbo (LOW PRIORITY)
@done Clean Modules list (keep lite.tbo, goblin, cletus, doj, elmo, matty) + add "CNprobe"
- @cancelled Make 7 clean QuickStarts for remaining modules // copy them on Tindie.
- @cancelled Get "ShortNames" in JSON
@done Put alt.tbo, tobo, loftus, tomtom, croaker, retroATL3 and wirephantom in retired modules + add "PU3090" phantoms in retired
@cancelled Remove sets in doc
@done Remake homepage in autodoc
@cancelled Clean obsolete versions in repos

2018-04-15 Documentation process

Testing goblin, then goblin + lite.pulser here
Testing new modules for ADC, lite.pulser, goblin here

2018-04-28 Back in the game

Superb work on the single element imaging here, or here.
@todo contact the author !
Interesting Signostic work on single element probes
Interesting vintage designs
See https://graph-tool.skewed.de/static/doc/index.html for mapping patents =)
nmap -sP 192.168.0.* This does a simple ping scan in the entire subnet to see which all host's are online.
Other:
- Ping your broadcast IP address ping 192.168.1.255 (may require -b on Linux)
- Now type arp -a. You will get the list of all IP addresses on your segment.

2018-05-01 HN number two

New post on HackerNews =), reached #2 position.

New people on the slack!

2018-05-06 news from shenzen

a new contributor from shenzen, yeayy! would be interesting to help develop a connection there
Interesting project at https://blackmesalabs.wordpress.com/2015/01/17/nanopi-project/
Updated the 20180430a experiment. Now the PU30 is a bit more visible (problem was I was loosing info when shifting data to an int..)
news from Nico's thesis

2018-05-10 Mojitos

After a couple of mojitos a couple of days back, the new un0rick board came out! Can't wait to test it.
Recommendation of Hurricane for piezos. Let's find out.
Need to improve the doc for un0rick

2018-05-11 A new article on the way

@done Resume work on article - Draft is here
@todo contact the guys from https://www.iith.ac.in/~raji/Cpapers/LPFB.pdf (check their prices)
Need to test different uses.
https://open-labware.net/projects/flypi/

2018-06-11 un0rick working

Seems the un0rick bugged because of a reset control
- TC1270ALVRCTR etait le mauvais composant, il fallait un TC1270ATVRCTR . Le niveau n'etait pas le bon.
Working version is here - version e.

2018-05-16 improving format system

@todo add Anna and Matthew to users list
better acquisition library
Interesting brochure on archive
Ultrasound tomography
Resolution on imaging - 1969

2018-06-16 improving format system

New ADC pHAT image (8G)
Some competition Ultratek UT350

2018-06-24 Slowing down hu

Wondering if/why I'm slowing down on producing.. Too many users / too many Q&A to answer?
Adding ultrasound pHAT to listen to and emit ultrasounds (15-25khz)
- @todo idea for the ultrasound phat : QuietShark (see https://twitter.com/Dymaxion/status/962385327599112193?s=19 )
- article idea for the un0rick doc: https://gregdavill.com/blog/2018/6/21/boson-camera-project-part-3
@todo Add new un0rick code, and documentation (both FPGA side, FPGA SPI level, Python)
@todo article un0rick article and pics
- reference to this http://innovations.bmj.com/content/2/2/78
- other book images

2018-06-25 Or not

Article: Impressive Development of a Low-Cost Medical Ultrasound Scanner Using a Monostatic Synthetic Aperture
- I'm a noob at this, but it seems that MFFS uses fixed focus piezos, but MSAS does focusing in the software (hence synthetic aperture) using a piezo of known size. That's an interesting alternative to focused piezos.
- Some other interesting insights, like using "Quality Assurance for UltraSound (QA4US) software" for image quality assessment, or also the architecture they used (an ARM, 14-bit ADC at 12Msps), or even the fact that the piezo is in direct contact with the skin, or a motor using a Voice Coil Motor.
- @todo add the MSAS principles to the un0rick article
Module
- define PI2 or get_rpi_version
- https://raspberrypi.stackexchange.com/questions/44858/how-to-transmit-a-binary-bit-stream-from-a-gpio-pin/44882#44882
- int rpi_version = LinuxUtilRPI::from(hal.util)->get_rpi_version();

2018-06-26 Random SDR

SDR for engineers http://www.analog.com/media/en/training-seminars/design-handbooks/Software-Defined-Radio-for-Engineers-2018/SDR4Engineers.pdf
HDR : https://github.com/adegirmenci/HDR-US
Updated biblio

2018-07-03 un0led

un0rick: playing with the I2C OLED screen using https://learn.adafruit.com/ssd1306-oled-displays-with-raspberry-pi-and-beaglebone-black/usage
http://ivory.idyll.org/blog/2018-how-open-is-too-open.html

2018-07-05 latex

Article: https://biomedical-engineering-online.biomedcentral.com/articles/10.1186/s12938-018-0512-6
Very nice article from an eu-funded consortium set of smes https://cordis.europa.eu/docs/publications/1258/125822911-6_en.pdf
Template for articles ? -> https://ctan.org/tex-archive/macros/latex/contrib/IEEEtran?lang=en for a great latex template
FFT for ice40 - https://github.com/mattvenn/fpga-fft

2018-07-21 TGC calibration

Tested TGC and class approach for Matty
Ongoing work with collecting bibliography
https://my.ncl.ac.uk/staff/nuconnections/item/low-cost-design-makes-ultrasound-imaging-affordable-to-the-world1

2018-07-21 Contacts

@todo try and get to artsens

2018-08-05 Phase II

Nine Chains to the Moon
Pile of notebooks on the desk & Cleaning flat
Making progress with benchmarks

2018-08-06 pyUn0 lib

check https://packaging.python.org/tutorials/packaging-projects/ for testing libs
Possibly this :
- https://ajminich.com/2013/06/22/how-to-easily-import-your-own-python-packages/
- or add a custom path to the lib
- https://stackoverflow.com/questions/37516579/importing-user-defined-modules-in-python-from-a-directory
- Interesting SimpleRick fork or see the image here.
@todo ebay Follow up Having a go on babay at a "ATL 720A", and two unspecified 5 and 10MHz probes.
- 720 for the "ATL MK-300I" .. and 724
- @todo ebay followup on 720, 724, AUSONICS
- @todo document ATL Apogee Ultrasound, ATL ADR 5.5 MHz / 7 mm
Ultrasound Transducer Probe for UM-4 (7081)

2018-08-11 Other probes

Tried to do some more work on steppers
Done finding echoes on a kretz probe

2018-08-12 A nice toshiba teardown

@todo get in touch with this teardown : http://electronicsplayground.blogspot.com/2018/02/toshiba-ultrasound-machine-teardown.html

2018-08-14 128Msps and beyond

Breaking the 128Msps wall
Improving the lib, removing some glitches
remains a glitch being the number of cycles below 8 bits !

2018-08-19 Some hv design

Proposed by Tomek: use a HV9110. " Ref is High Voltage DC/DC Converter for Supertex Ultrasound Transmitter Demoboards"

2018-08-20 Some shopping

@todo ebay Followup on the DIASONICS C PROBE FREQUENCY 10 MHZ P/N 100-1071-00 S/N 1466
hv check out http://www.analog.com/media/en/technical-documentation/application-notes/an118fb.pdf
or https://www.maximintegrated.com/en/app-notes/index.mvp/id/1751
- @todo use MAX5025 to test a HV runner ?
- http://www.analog.com/en/products/lt8710.html
RPi + ice40 : https://hackaday.io/project/7982-cat-board/log/46117-it-just-keeps-getting-easier

2018-08-20 Got 724A

Trying to get some connectors
Some intel make me think that's a duplex probe for MK300, MK450 or MK600. Preliminary tests show a stepper motor.

2018-08-23 Updated workplan

Wait for ATL plug
Get VHDL code
Push updated code, including
Test probes
identify motor + compteurs

2018-08-26 New Matty v1.1

Got a v1.1 firmware out, for 0 < nCycles < 0xFFFF
Reviewed Readme
Progress on the article
Got a 2GB image fully valid for RPi. Python: Jupyter, Scipy, Numpy, .. all gets on.
Added some utilities to flash directly the flash.
Updated history and process details.

2018-08-27 Adding iceprog

iceprog mybin.bin works well to flash on the un0rick. just plug in the cable, put a jumper on the RPi/FT header, then iceprog mybin and voila =)

2018-09-12 Desperatly at work

not a lot of progress..
un0rick's first batch is sold out!
Some cheap piezos? https://news.ubc.ca/2018/09/11/could-a-diy-ultrasound-be-in-your-future-ubc-breakthrough-opens-door-to-100-ultrasound-machine/

2018-09-16 Most secure password

https://mostsecure.pw/: H4!b5at+kWls-8yh4GvQ hahaha
Congrats to william: https://www.rtl-sdr.com/rtl_ultrasound-using-a-piezoelectric-transducer-with-an-rtl-sdr-to-create-an-ultrasound-imager/ =)
https://github.com/cliffordwolf/icotools/blob/master/examples/icezero/icezprog.c icezprog
@todo Check for un0rick github badges (counter, pypi overag, doi zenodo, ... )
- Compteur: http://hits.dwyl.io/wlmeng11/rtl-ultrasound
- PyPi: https://pypi.org/project/rtl-ultrasound/0.1.0/
- coverage x% (coveralls.io)
- DOI Zenodo:
- readthedocs.io
First test with pylint not the cleanest of codes

2018-09-18 Teardowns

Geeky! Looking at https://www.youtube.com/watch?v=49D3fhGpb7w
https://fccid.io/XSB2300A/Internal-Photos/Internal-Photos-2353839

2018-09-30 Teardowns

How fast times run when you're stuck on a big project..
Reading more on fpgas
- https://www.edaplayground.com/ for verilog tests online
- https://hackaday.com/2018/05/19/parallel-programming-for-fpgas/
- https://hackaday.com/2018/09/26/learn-verilog-in-your-browser/
- GB and NES on UP5K https://github.com/daveshah1/up5k-demos
@todo do a un0pHAT - HV7360 or using HV7361 (price: 7$ -- see HV7361 Typical Application Circuit on datasheet -- vs 2x (1.87 + 1.68)+1.5 with MD1210K6-G, and MD0100 TC6320TG, grand total of 8.6$ )

2018-10-06 pHATrick

hehe thinking about bad puns on the new board. Previously un0pHAT, or liteRick
concept ongoing
- name made me laugh .. patrick, fat rick, hat trick ?
Made some progress on the single sensor imaging article -- litterature review
un0rick v1.1 (two channels) ordered. Quite some stress on flash chips, possibly to remove from next iterations
- No more Winbond flashes!
- got some by some brokers...
@todo better readmes for un0rick -- https://github.com/matiassingers/awesome-readme
@todo push a python lib for un0rick
Waiting a un0rick v1.0 to retry some tests
https://iainews.iai.tv/articles/how-kierkegaards-idea-of-idleness-can-help-us-diagnose-21st-century-busyness-auid-1150
@todo 8bit art for icons and todos
@todo source a Bion PSI-400
writing on apogee5MHz and apogee10MHz
- got into the 10Mhz, some piezo, and another piezo + motor =)
- updating RetroATL3

2018-10-14 RPi SPI speed

https://raspberrypi.stackexchange.com/questions/45607/max-spi-transfers-sec-speed-using-wiringpi
Seems to top at 1Msps with fast clock
ADCS747x / AD7476
- http://www.analog.com/media/en/technical-documentation/data-sheets/ad7476_7477_7478.pdf
- OP467 + AD711 ?
Trying new matty on old probes
- @todo try matty on a apogee5MHz once opened
- @todo try matty on a ausonics75 once opened
- @todo try matty on a 724A with connectors

2018-10-28 some ultrasound tests

http://www.szynalski.com/tone-generator/
Tests with beacons
- Beacons https://github.com/kelu124/ultrasHound/tree/master/beacons
- and results : https://github.com/kelu124/ultrasHound/tree/master/pHAT/20181028b
- usHound v2.0 in the pipe !

2018-11-25 back from family holiday

@todo m5stack client for un0rick
@todo Explain aim on tinyfpga discourse
un0rick v1.1 dual SMA received
- @todo check why no reset on v1.1
@todo order one phat
@todo Read https://blog.tindie.com/2018/08/secrets-making-successful-product-tindie/
@todo use https://github.com/g2384/VHDLFormatter on MATTY VHDL
@todo check https://github.com/benkrasnow/EL_driver_multi/blob/master/EL_driver_multi_schematic.pdf driver up to 200V
FPGA at Amazon: https://aws.amazon.com/ec2/instance-types/f1/
@todo on https://pinout.xyz/ for un0rick and minimatty
@todo http://m.nautil.us/blog/12-mind_bending-perceptual-illusions for illustrations
check HV supply of http://ezphysics.nchu.edu.tw/prophys/electron/reportdata/EDNpaper/HVDCDCWilliams.pdf
@todo loot badges: https://github.com/bevry/badges

2018-12-10 slowing down

Close to year since matty was designed !
https://github.com/goran-mahovlic/ulx3s-PMOD for view of what PMODs should be like
- @todo to correct MATTY V1.1 revA
Reviewing a bit of MATTY verilog
@todo command line for pyUn0 following http://www.catb.org/esr/writings/taoup/html/ch10s05.html
@todo add to pyUn0 compressed acquisitions ( jsons of 1 Line, json of 10 lines, 64 Msps, 32Msps)

2018-12-17 Some gadgets

auto lo usb0 allow-hotplug usb0 iface usb0 inet static address 169.254.97.1 netmask 255.255.255.0 network 169.254.97.0

Bbox-089C716D // mimite2000

777 commits!
Tracing table
New image to come for "goblin", ethernet gadget, vnc enabled, ssh, and others

2018-12-16 UNICODE someone

https://unicode-table.com/fr/#miscellaneous-mathematical-symbols-a
sudo avrdude -c arduino -p m328p -P /dev/ttyUSB0 -U flash:w:grbl.hex for flashing an hex to an arduino uno (Plotter XY table)

2018-12-16 some Fpga stuff

Some bins
- fa6a7560ade6d6b1149b6e78e0de051f /home/kelu/ultrasound/un0rick/software/MATTY.bin
- 4c4c1476fe43503b2a32ca39a59b3c51 /home/kelu/ultrasound/echomods/matty/v1.1/MATTY_v1.1a.bin
- dc9ece10627d97eec40cbe3ed872cf39 /home/kelu/ultrasound/echomods/matty/v1.1/MATTY_V1.1b.bin
- 7cbf3d11454ae62d70a5aa8264d74bae /home/kelu/ultrasound/echomods/matty/v1.01/MATTY_un0rick_20180826.bin
- 49ed003fae3a312590fe99a2fa90392c /home/kelu/ultrasound/echomods/matty/v0.1/MATTY_Proto_v0.1.bin

2019-01-02 Happy new year

Interactive fiction
- https://www.ifarchive.org/
- https://github.com/rossumur/Zorkduino
https://spun.io/2018/12/15/lessons-from-running-a-small-scale-electronics-factory-in-my-guest-bedroom-part-1-design/
https://www.smithsonianmag.com/arts-culture/first-time-20-years-copyrighted-works-enter-public-domain-180971016/?preview
Mezzanine connectors ?
- https://www.reddit.com/r/FPGA/comments/ab46mk/ice40_mezzanine_style_pcie_board_design_has/
- https://fmchub.github.io/
https://www.reddit.com/r/UNOMOD/ : Ultrasonic Neuromodulation (UNOMOD) is a subreddit specifically designed to enable an open and public discussion around the field of stimulating the brain using Ultrasound.

2019-01-04 work again

Been working on the python lib
http://bwlampson.site/33-Hints/Acrobat.pdf for Human Interface Design ..
@todo read Designing Video Game Hardware in Verilog for verilog games design
@todo read IF books and MUSH
@todo coverage for pyUn0 lib, including pypi, https://shields.io/#/, zenodo,...
Gitbook gestalt
@todo sterling: HV7361 / HV7351 SPI logic ?

2019-01-05 Manual for boards

Reworked documentation
REtromanual Basic

2019-01-12 NDT and others

@todo explore NDT with Jorge
http://www.ireneposch.net/1-bit-textile/ -- awesome work of textile innovation #art
Starting a new 5 batch of v1.1
lower power jewellery: http://www.ireneposch.net/linkpin/
@todo un0rick / lit3rick : install an initial delay (after trig)
MF costs: check how it evolves
@todo EB - ESP32 + ICE40
- https://www.elektor.fr/esp32-pico-kit-v4 -- https://www.elektor.fr/media/catalog/product/cache/3/thumbnail/9df78eab33525d08d6e5fb8d27136e95/e/s/esp32-pico-kit-dev-board-v4-layout.png
- add gyro, eink, LEDs, photodiod, IR ?
- 1 PMOD = 8 signals means if 24, 3PMOD possible
- Size: PHAT is 65x30, Business card is 85x50
- 80x45 as an objective ? -> 2 PMODs on opposite to RPI connector, then 2 PMODs on sides
- eINK display for ESP ? Eg ikny phat : 212x104 pixel
- badgy 2.9" 296x128 pixel
- TTGO ESP32 2.9" display
- Tilt sensor / gyro / .. ?
- DEFCON2018 badge https://www.cio.com.au/slideshow/355919/defcon-badge-unlike-anything-ever-seen/
Working on the WVP

2019-01-08 Awesome readmes

READMEs: https://github.com/PharkMillups/beautiful-docs
AWESOME LISTS : https://github.com/sindresorhus/awesome
https://github.com/sindresorhus/awesome/blob/master/create-list.md
https://github.com/sindresorhus/awesome/blob/master/pull_request_template.md
@todo rework echomods page
@todo rework un0rick page (with new logo / gifs / support / ...)
@todo : add options to pyUn0 lib

2019-02-08 Moocs to follow

@todo follow the specialisation from beg of march ? https://www.coursera.org/specializations/data-science-python
https://github.com/coursera-dl/coursera-dl
fun https://blog.floydhub.com/instagram-street-art/

2019-02-13 Elementary Basic as Chronicled by John H Watson

https://github.com/zacharyvoase/humanhash
https://www.abebooks.com/servlet/SearchResults?isbn=9780394707891&n=100121503&cm_sp=mbc-_-ISBN-_-used
- @todo include the book as an insipration for lit3rick ?

2019-02-15 Moar piezos

abil
- https://www.alibaba.com/product-detail/GOWORLD-submersible-piezoelectric-underwater-immersible-ultrasonic_60696546066.html?spm=a2700.8592591.0.0.fcd810a9Lk6hky
Jorge
- https://www.alibaba.com/product-detail/NDT-Straight-Angle-Beam-transducer-sensors_60752888953.html?spm=a2700.7724838.2017115.198.12067c84XcXzww
- https://www.alibaba.com/product-detail/yushi-PT-12-probe-ndt-ultrasonic_60557426233.html?spm=a2700.7724838.2017115.222.12067c84XcXzww
@todo prepare a page for NDT piezos.. the same way there is one for probes.. or on same ?

2019-02-17 lit3rick interfacing

https://forum.mystorm.uk/t/raspberry-pi-zero-connection/393/21
icezprog : https://github.com/cliffordwolf/icotools/issues/3 and some customising

2019-02-24 Rework on todos

@todo lit3rick vF : add rounded edges, connections on other pins from the board for flash CS, passer all IOs sur le header RPI, cacher les SCK du controle HV et back de la carte: passer un header go-through.
UP5K flashing
- UP5K RGB: https://github.com/cliffordwolf/icestorm/tree/master/examples/up5k_rgb
- Upload a FPGA ice40 bitstream via curl using a ESP32 in arduino : https://github.com/kelu124/ice40_esp32_bitstream_upload
- Why not through a M5STACK ?

2019-02-26 First bin on up5k

Yeayyy using an esp32 with the lit3rick flash issue

2019-02-27 IP and IA

Search for: neural networks "derivative works" of datasets
Lex Fridman on Twitter: If a neural network generates an image, who owns the copyright? The owner of the dataset that the net was trained on? The designer of the network architecture? The person running the code? Or... the AI system itself?
@todo echomods: Rewrite landing page echomods
@todo include on echomods readme : Support paragraph as in https://github.com/pi-hole/pi-hole

2019-03-18 Random stuff

@todo @toorder hv9150db1 - LED drivers (MAX?) - SMAs
@tocheck
@todo backpack for #NSA1166
- https://www.nxp.com/docs/en/data-sheet/SC18IS602B.pdf - I2C to SPI: 2.41€ 568-13691-1-ND #NSA1166
- LED driver : MAX7219 : 9€ - MAX7219CWG+-ND : ordered for tests #NSA1166
Veille ebay: TSA1605A, NSM1416, HP5082-7415, siemens DL1416
@todo better landing page:
- Include LOGO & TAGS
- Include badges
- Better index page as follows
- A. Intro
- B. List of previous projects
- C. Summary here
- List of experiences
- List of modules
- Single sentence with list of probes and link to those
- D. TODOs
- E. LINKS
- Biblio, articles, list of resources, ...
- Tindie, slack, Community
- F. DISC/LICENSE

Other pages under /include/worklog/

Source articles : @article
Other articles ? Add all sentences with hastag, remove it + link, strip, add.
Source bibliographie from biblio

2019-03-19 Random stuff II

https://medium.freecodecamp.org/the-easy-way-to-set-up-docker-on-a-raspberry-pi-7d24ced073ef
Add: LM96511 : http://dx.doi.org/10.1590/2446-4740.0700 -> MD2131 --> AFE5805 -->
https://github.com/Wookai/paper-tips-and-tricks
https://www.raspberrypi.org/forums/viewtopic.php?t=186435 for RPI and GPIO and SP
- sudo gpio mode 14 alt0 (itoo with 12 and 13 to reset SPI pins to original function)
+80V and -80V from 8V, using HV9150 and a MAX1846

2019-03-24 Still need to work more

@todo first shots with lit3rick
@todo harmonize between lit3rick, pHATrick, minie, minny
@todo receive lomos and test for NDTs

2019-04-07 Beginning of port to lit3rick

First experiment - blinky on C1 to C3 OK, HILO..not.
Moar articles to the biblio
New DC/DC boosts?
https://github.com/Wookai/paper-tips-and-tricks
https://www.raspberrypi.org/forums/viewtopic.php?t=186435 for RPI and GPIO and SPI
Verilog DSP:
- http://zipcpu.com/projects.html
- http://www.spiral.net/hardware/filter.html

2019-04-03 Time flies

Not enough time to work!
OSS in companies https://spiceprogram.org/assets/docs/Futurice-Companys_Guide_To_Open_Source_And_Social_Impact.pdf
need updating lit3rick to v1.4
- Round edges
- change ADC for Matty old one
- i2c thermometer
- remove header for SPI for voltages
- change flash to winbond

2019-06-11 Looooong time

Still working on minie bin's
lots of links to record
Pics old america: http://www.american-pictures.com/english/book/American%20Pictures-small-size.pdf
lit3 update
- update flash
- cut corners
- MCP9808 for temperature onboard
- filtre evacuation d'energie entre pGA et ADC
- passer en 12 bits ?

2019-06-11 Air Quality rants

Thanks Hackolite for putting my brain on this =)
- https://www.rci.fm/infos/risques-naturels/une-partie-de-la-population-evacuee-terre-de-bas-en-raison-des-sargasses
- ESP32, uFL, uSMA, VDD controled via pins, ...
- https://lastminuteengineers.com/esp32-sleep-modes-power-consumption/
- air quality ?

Boards:

Sensor

Sleep:

AA rechargeable ?

https://hackaday.com/2017/12/03/minimizing-esp8266-battery-drain/

Battery sensing: https://github.com/rlogiacco/BatterySense + a p-channel MOSFET Q1, a PNP transistor Q2

2019-06-15 VGA and k210

Would be fun to have a simple ACQ + display setup in VGA of a 120us line on a 640x480 display
- https://timetoexplore.net/blog/video-timings-vga-720p-1080p
- Check with uF
  - Availability of IOs for VGA on a lit3
Video processing ?
- k210 for https://www.seeedstudio.com/Sipeed-MAix-BiT-for-RISC-V-AI-IoT-p-2872.html for video fun
Working with cheatsheets - https://www.federaltimes.com/opinions/2019/04/18/dear-bureaucrat-how-can-i-work-with-and-around-my-agencys-useless-computer-system/
Holidays:
- Scilly Isles
- Ethiopia
- Corfou
- Argentina : longtemps =)
- CAN / FXH / ...

2019-08-30 FFT and ice40

Summer time and deconnection !
some progress on lit3
- getting help form @ico_TC : https://twitter.com/ico_TC/status/1165699274652475392
- going back to UW, checking with Farad too.
- Need to stop bleeding resources ;)
- Need to fix thermometer
Gathering some signal processing on fpgas
- https://github.com/mattvenn/fpga-fft/blob/serial/docs/fpga_usage.md

2019-10-26 Some lit3 progress

Good progress, stupid capa was in the way on ADC clock. Now acquisitions seem more okay:
- here some good experiment
@todos updates on new pHAT
- remove this capa, remove i2c pullups for the thermometers (that was cost 5$ ! :/ )
- connecter le ice40 au i2c rpi
- pouvoir connecter des ios sur l'uart du rpi
- router les gpio daughter existantes plutôt sur les pins pcm du rpi pour un jour essayer de sortir des données en i2s (GPIO26, 20, 21, 18)
- du coup, mettre possiblement les Pulse controls sur des GPIOs non spécifiques comme GPIO05, 06, 13, 19.
- Niveau header RPi, on peut connecter les SPI_EXT MISO / CS du coup.
- Use 5 first bytes of a read to store the bin number / board ID ?
Need to make progress on this RTL-SDR for ultrasound ;)
@todo find the right jekyll theme to leave gitbook
- see https://help.github.com/en/github/working-with-github-pages/adding-a-theme-to-your-github-pages-site-using-jekyll
- https://pmarsceill.github.io/just-the-docs/ seem to fit the bill =)

2019-10-27 Again lit3 progress

Dynamic DAC seems better - however some IOs are off.
CLosely here, and then some: hardware finetuning (TMP and ADC C at minimum)

2019-11-24 10km Paris Centre

Ran again 10km
lit3rick on final form to be delivered by 2/12.
Andrew for some symbiflow support ? DFT + i2s ?
Got the sw45b probe off. Interesting designs.
@todo hack the diasonics heads.
Ported the pyUn0 for un0rick to python3 .. yeay. Thanks to Fab's pull request.
Awesome SAO: https://hackaday.io/project/164346-andxor-dc27-badge/log/165849-dc27-doom-sao-hurt-me-plenty
@todo: SAO on up5K: https://github.com/ANDnXOR/sao-reference-designs
- RGB's
- USB
- 2 GPIOs: for what ?
- mini OLED ?
- SD connector
- mini MEMS microphone
- touchpad

2019-12-06 St Niklaus

lit3 received, doesn't burn. yet. icoprog can flash the flash. but fpga won't boot from it.
Connections seem OK
- icebreaker-sch.pdf says the connections are fine
possibly need to make clean icoprog
or to swap IOs for programming, while
beware, for flash programming, SPI_SS needs to be kept floating high. Floating.
@todo keep an eye on "BRUEL KJAER ULTRASOUND" =)

2019-12-12 Article ongoing

The article for the conf is quite ready. Thanks to William, Carla, Jorge.
GE amongst my clients !
@todo analyse protoelectronics (cf Leonie) for short runs -- http://protoelectronique.com/

2019-12-14 US Badge

@todo a small US badge see [SAO DOOM]
- 8x8 LED matrix + driver (max7219 // IS31FL3728 (1x8x8) / 31FL3736 pr 12x8, including breathing - QFN40 / IS31FL3731, 2x8x8, QFN28)
- i2c simulated EEPROM
- MEMS loudspeaker
- US microphone
- SAO 2x3 - V1.69bis standard
- USB-C
- FTDI
- FLASH
- UP5K
- Breakout of remaining IOs + SPI / I2C
@todo PMODs US:
- 2x8 : 10bits+1 ADC, MOSI, SCK, SS1, SS2, HILO (ADC, DAC TGC, HILO, ..) based on AD8332
- 1x8 Trig, HVP, HVN, PDAMP, i2c, i2c, EN, IO

2019-12-17 Holidays planning

@todo use the driver
- test on several probes
- get driver from aniss
test with BLDC on some probes
@todo redo probes sheets
- Have all in one sheets
- teardown subpart
- experiment subpart
- others ?
Thinking of the un0rick website.. have subdomains like experiments, probes, ... for general aspects from echomods ?
@todo redo the geography part.. using geopandas ?

2019-12-31 Last of the year

Ultrasound stuff

@todo integrated mouse optics in the article, from "A Free-Hand System of the High-Frequency Single Element Ultrasound Transducer for Skin Imaging"
@done my objectives at https://github.com/kelu124/un0rick/blob/gh-pages/partners.md
MUX
- https://raspberrypi.stackexchange.com/questions/80221/using-pythons-rpi-gpio-library-to-manually-toggle-spi-chip-select-is-this-ok
- https://www.maximintegrated.com/en/products/analog/analog-switches-multiplexers/MAX14866.html
@todo Documentation - update for lit3 once it is ready, with http://2012.oshwa.org/files/2012/07/Wozniak-OHS2012-Final.pdf, http://2011.oshwa.org/files/2011/09/Wozniak-OHS2011.pdf, and https://cdn-blog.adafruit.com/uploads/2011/09/w0z-OHS2011-v1.pdf
Motors
- DRV8313, L6234
- Brushless DC (BLDC) motor with Arduino – Part 2. Circuit and ...
- SN754410NE
FFT at https://github.com/mattvenn/fpga-fft
AFE5801 on a PMOD ? + MAX14806 ?
@todo : Analyse de la compétition (lecoeur, www.lecoeur-electronique.net/, https://www.industrie-techno.com/article/des-ultrasons-pour-controler-les-revetements-metalliques.54136 (siderus), https://ndt-testing.org/our-services/ultrasonic-testing-pulse-echo-method/, https://www.nde-ed.org/EducationResources/CommunityCollege/Ultrasonics/Introduction/description.htm , https://www.ndtclassroom.com/blog/2018/1/23/ultrasonic-testing-pulse-echo-technique https://ndtvendor.com/categories/69-usb-instruments/364-pciut3100-all-in-one/ https://ndtvendor.com/categories/69-usb-instruments/365-compact-pulser/ http://eurosonic.com/en/products/ut-solutions/tfl-110.html http://www.usultratek.com/products/picopulser.htm http://www.ultrasonic.de/index.php http://tecnatom-ndt.com/product/ultrasonic/sonia-fprhf1/ http://www.mec-ndt.co/ndt_products_desc?code=97 https://www.insight-ndt.com/ultrasonic/8channel.html https://ndtsupply.com/dakota-ultrasonics-pvx-1.html )
@todo documentation ghpage to update, https://help.github.com/en/articles/adding-a-jekyll-theme-to-your-github-pages-site
@todo encode lib in npz : https://stackoverflow.com/questions/11511705/base64-encode-a-zip-file-in-python and check dependences with https://poetry.eustace.io/
@todo up5k update - https://blog.idorobots.org/entries/upduino-fpga-tutorial.html for the refs (includes block RAM, SB_SPRAM256KA, but i2c and SPI too (SB_SPI and SB_I2C)) -- see refs at https://www.latticesemi.com/~/media/LatticeSemi/Documents/TechnicalBriefs/SBTICETechnologyLibrary201608.pdf

Others

https://feeding.cloud.geek.nz/posts/encoding-wifi-access-point-passwords-qr-code/ qrcode wifi
@todo get a spidriver https://www.crowdsupply.com/excamera/spidriver

SAO:

MEMS : SPH0641LU4H-1 (PDM) et IS31FL3728 pr 8x8 en i2c
icebling: https://electronut.in/ice-bling-making-led-earrings-with-an-fpga/

2020-01-11 Silent is back

@todo Repushing some silent experiment - using it as a benchmark for lit3rick and un0rick boards
@todo Need to repush libpyUn0.
@todo get somes boxes to sort VNA, piezos, attiny's stuff
@todo SAO for Belgrade !
- SAO: FT232RQ - https://learn.adafruit.com/programming-spi-flash-prom-with-an-ft232h-breakout/overview
- upduino Flash - ice40 connection

2020-01-12 Yeay on vit3lite

FFT generator : https://zipcpu.com/dsp/2018/10/02/fft.html
Corresponding : https://github.com/ZipCPU/dblclockfft

2020-01-18 MF and short

Manuf confirmed a LDO was rotated 90degrees. Means tests on lit3rick v1.3 can now be done.
@todo silkscreen v1.3 to be updated.
daugther board on esp32 m5stack for viz ?
@todo get https://github.com/tobozo/M5Stack-SD-Updater to add bins
- to flash
- to run tests
- to do single acqs and details
- to stream i2s
test INMP441 ?
SAO ideas: apa102 LEDs ( WS2812B-2020 also, 2x2mm)
- see https://www.sparkfun.com/products/15047 - SparkFun LuMini LED Matrix
@todo lit3rick examples : complilation : https://github.com/FPGAwars/apio-examples/tree/master/iCE40-UP5K/
- https://github.com/mmicko/fpga101-workshop for LED, button, https://github.com/mmicko/fpga101-workshop/tree/master/tutorials/12-RiscV

2020-01-26 Streamlit fun

@todo explore bivi's https://github.com/streamlit/streamlit and https://github.com/samuelhwilliams/Eel
- https://towardsdatascience.com/quickly-build-and-deploy-an-application-with-streamlit-988ca08c7e83
@SAOLIT : ATtiny861A / ATtiny84A ?

2020-02-15 Nothing new

Having fun with StyleGans

=======
